Specifications
Model Number :
EC4-Br2-5
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
3-5work days
Sensitivity :
-650 ± 200 nA/ppm (negative current)
Zero current :
± 20 nA
Range :
5 ppm
Repeatability :
2 %
Lower Detectable Limit (LDL) :
≤ 0.05 ppm
Resolution (16Bit ADC) :
< 0.01 ppm
Maximum overload :
10 ppm
Linear range :
5 ppm
Description

EC4-Br2-5 3 Eletrode Electrochemical Gas Sensor Zero Bias High Sensitivity Excellent Sensitivity At Low Temperatures For Leakage Detection TLV-monitoring General Industry

Features:
• Zero Bias
• High Sensitivity
• High Selectivity
• Excellent Sensitivity at
Low Temperatures
• Stable Zeropoint
• Water Based Electrolyte
• Double Sealed Housing for Advanced Leakage Protection

Typical Applications:
• Leakage Detection
• TLV-monitoring
• General Industry
• Semiconductor Industry
• Emissions
• Industrial Safety
• Environmental Monitoring
• Portable and Fixed
Point Applications
• TLV Monitoring
• Water Treatment Plants, Swimming Pools, Chemical Industry

Temperature Range -20 to 40°C
Humidity Range (non condensing) 10 to 90 % R.H
Pressure Range 800 to 1200hPa
Operating principle amperometric
Bias voltage 0 mV
Recommended load resistor 220 Ω
Warm up time < 60 s
Long Term Sensitivity Drift < 1 %/month

EC4-Br2-5 3 Eletrode Electrochemical Gas Sensor Zero Bias High Sensitivity Excellent Sensitivity At Low Temperatures For Leakage Detection TLV-monitoring General Industry
