Fumigation Free Green Plants Fiber Wooden Pallet Making Machine
Fumigation Free Green Plants Fiber Wooden Pallet Making Machine
Fumigation Free Green Plants Fiber Wooden Pallet Making Machine
Fumigation Free Green Plants Fiber Wooden Pallet Making Machine
Fumigation Free Green Plants Fiber Wooden Pallet Making Machine
Fumigation Free Green Plants Fiber Wooden Pallet Making Machine
Specifications
Brand Name :
ThoYu
Model Number :
TYYJ-1000
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, D/A, Western Union, MoneyGram
Supply Ability :
10 sets per month
Delivery Time :
30-40 working days
Packaging Details :
Strong wooden pallet for global shipping
Product name :
Plants Fiber Pallet Making Machine
Voltage :
Customized
Pallet capacity :
240 pieces/day
Motor power :
18.5 kW
Pressure :
0-1000 t
Total Weight :
22 tons
Description

Fumigation Free Green Plants Fiber Pallet Making Machine

Introduction of Fumigation Free Green Plants Fiber Pallet Making Machine

Plants fiber pallet making machine is different from pallet nailing machine, it uses the raw materials contain plant fiber to make pressed pallet, which is an eco-friendly green pallet production equipment.

Plant fiber is a combination of cellulose and various nutrients to produce filaments or flocs, for plants with support, connection, wrapping, filling, etc., widely found in the plant culm stems, roots, fruit, and fruit shells.

Plants Fiber Pallet Making Machine Parameters

Plant fiber pallet making machine
Model TYYJ-1000 TYYJ-1200
Voltage customized customized
Capacity 240 pcs/day (24 hours) 240 pcs/day (24 hours)
Power 18.5 kW 18.5 kW
Hydraulic cylinder diameter 350 mm 380 mm
Hydraulic cylinder quantity 4 pieces 4 pieces
Pressure 0-1000 tons (adjustable) 0-1200 tons (adjustable)
Shaping cycle 350 seconds 350 seconds
Weight 22 tons 22 tons
Dimension 2000*1400*3500 mm 2000*1400*3500 mm

Fumigation Free Green Plants Fiber Wooden Pallet Making Machine

Plants Fiber Pallet Making Machine Application

Plants fiber pallet production method maximizes the reuse of used plant waste, such as tree branches, wood offcuts, palm tree leaves, coconut shells, sunflower husks, sugar cane bagasse, etc.

Plants Fiber Pallet Advantages

  1. Space-saving in transport and stacking. Pressed plants fiber pallet can save space up to 70%, the height of 50 pieces of plant pallets is about 2.73 meters.
  2. No fumigation for easy export. The plant fiber pallet is produced with high pressure and high temperature, so it meets ISPM15, and easy to export.
  3. Strong load capacity. The static load of plant fiber pallet can reach 8 tons, and the dynamic load is more than 3 tons.
  4. No nails. Smooth surface without nails is friendly to load some goods which easy to broke.

Fumigation Free Green Plants Fiber Wooden Pallet Making Machine
