Specifications
Place of Origin :
Nanjing, China
Model Number :
HHT
MOQ :
1000 kilograms
Price :
$1.30/kilograms 1000-4999 kilograms
Type :
Push-Back Pallet Rack
Material :
Steel
Feature :
Corrosion Protection
Use :
Warehouse Rack
Depth :
2-5 pallet depth
Weight Capacity :
300-1500kgs/pallet
Width :
1-2 pallet width
Height :
1500-12000mm
Usage :
Industry
Color :
Blue, Orange, Yellow, Green etc.
Quality :
Industrial
Description
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep

Push-back pallet rack is for high density storage. The depth is usually within 5 pallet positions. The rack takes "first-in-last-out (FILO)" access mode.

Characteristics

-Applicable to warehouses with high cost per unit area, such as cold storage, warehouses in prime locations in downtown, etc.
-Provide 20%-30% selectability
-Both safety and operating efficiency are higher than drive-in racks (drive through racks).
-Compared with adjustable pallet rack, it increases the utilization rate of the ground by about 60%.
-It can be used with a reach forklift or a counterbalanced forklift, and the forklift operation requirements are lower than drive-in pallet rack.

Components

The main components are upright frames, beam, support rail, and carrying cart. The rack is bolted structure and easy to dismantle
and install to a new place.
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Product Information
Rack Type push back pallet rack
Rack Cost Low, Medium Low,Medium,√Medium high,High,Higher
Pick-up Mode first in, last out(FILO)
Structure knock down or assembled
Forklift Asile around 3200mm,depends on customer's forklift parameter
Load Capacity & Dimension Load capacity ≤1500kgs/pallet
length 950mm～2700mm
depth/width 1700mm～5000mm
height ≤9000mm
level ≥2
Components core components frame(upright,also called column or post,bracing,base plate,fasteners),beam,support rail,cart,spacer
highly recommended components upright protector,frame protector
Core Components Specification
(mm)		 upright section face 80,90,100,120
height 60,67,70,95,135
thickness 1.5,1.8,2.0,2.3,2.5,3.0
adjust step 75
beam section height 80,100,110,120,130,140,160,180
width 50
thickness 1.5,2.0
Material Q235(ss400),Q355(S355B,S355JR)
Finish Epoxy resin electrostatic spraying(powder coating),galvanized
Coating thickness no less than 60um for average thickness for powder coating
Color ral5015(sky blue),ral5005(signal blue),ral2004(pure orange),ral1003(signal yellow),ral7035(light grey)
Customized colors are available when order above 2*40gp containers

Store & Withdraw

Loading

Carrying cart runs along the inclined support rail. 1st pallet is placed on the carrying cart, 2nd pallet pushed back 1st pallet into the rack, 3rd pallet push the front 2 pallets into rack, the rest keep the same operation.

Unloading
Pallet at the pick-up end is carried out first, the next pallet slides to the pick-up point by gravity for unloading, other keep the same. Unlike drive in pallet rack, forklift truck don’t drive into the rack
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Packaging & Shipping
To suit different clients needs,HBrack use different storage method.Following are rules followed. For container order: stretch film+carton board+packing belt+plywood stick+plywood pallet leg For less than container order:plywood box or other that can keep the product safe during transportation Other: based on clients' needs, such as vacum packing etc.
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep
Density Cold Room Storage 5 Layer Blue Push-Back Pallet Rack System for 3 Pallet Deep

FAQ

Question 1: Are you factory or trading company?

Answer 1: We are factory and also do trading products related to warehouse rack.

Question 2:Do you provide sample? Is it free or extra?

Answer 2: We provide sample parts free charged and you just need to pay the freight. When need whole sample rack for testing the possibility, please contact us for sample cost.

Question 3: I’d like to visit you. Which city should I go?

Answer 3: We are in Nanjing. When needed, we can help you book hotel, traffic ticket. And we will pick you up to the destination place. We have sales person and driver who will be with you during the visit. You don’t have to worry about the traffic matter.

Question 4: Why choose you?

Answer 4: 1. HBrack have engineers who are professional in design warehouse rack more than 10 years and could handle from simple structure to complex one. 2. Your money is safe with HBrack. We accept trading through 3rd party. The sales person have rich experience in warehouse rack, all the personal information is trackable. 3. HBrack offer different design to help client control budget.
