MSQ-30 current transformer 40/5a busbar current transformer
MSQ-30 current transformer 40/5a busbar current transformer
Specifications
Place of Origin :
Zhejiang, China
Brand Name :
customized
Model Number :
MSQ30
Usage :
Current
Phase :
Single
Coil Structure :
TOROIDAL
Coil Number :
AUTOTRANSFORMER
Usage: :
Current
Coil Structure: :
Toroidal, MSQ current transformer
standard: :
IEC60044-1,BS7626,VDE0414
Coil Number: :
Autotransformer
Ratio: :
5/5A--300/5
Sheathing material: :
PC,ABS
Type: :
Busbar current transformer
Rated voltage: :
0.72KV
Frequency: :
50/60Hz
Packaging Details :
one pcs packed one box, 60pcs packed one carton
Port :
Ningbo
Supply Ability :
10000 Piece/Pieces per Month
Price :
$1.80 - $2.10/pieces
Description
Product Description

MSQ-30 current transformer 40/5a busbar current transformer

MSQ Current Transformers are suitable to be applied to test, control, display and record the running of the electrical equipment, in the AC circuit with the rated voltage value below 0.72KV and the frequency of 50-60Hz, mainly used in combination with measure meters like ammeter, watt-hour meter, control relayu etc.

MSQ current transformer / MFO current transformer:

1.Model:MSQ-30,MSQ-30B,MSQ-30T,MSQ-40,MSQ-60,MSQ-85,MSQ-100,MSQ-125

2.Standard:IEC60044-1

3.Certificate:ISO9001:2000, ISO14001:1996,CE

4. Professory transformer manufacturer

Specifications

1.Rated current:5/5A-6000/5A,
2.Secondary current :5A.1A

3.Rated voltage:0.72kV
4.Rated frequency:50/60Hz
5.Class of accuracy:0.5~1.0
6. Rated security coefficient :FS<5
7.Ambient Temperature Range:-20 to +80

Type Current ratio(A) Rated power(VA) Rated
Class:0.5 Class:1 Frequency(Hz)
MSQ-30 30/5 5 5 50/60
40/5 5 5 50/60
50/5 5 5 50/60
60/5 5 5 50/60
75/5 5 5 50/60
80/5 5 5 50/60
100/5 5 5 50/60
150/5 5 5 50/60
200/5 5 5 50/60
250/5 5 7.5 50/60
300/5 10 10 50/60

NOTE: We can supply some color if customer need ,like Grey ,Black and Blue

MSQ-30 current transformer 40/5a busbar current transformer MSQ-30 current transformer 40/5a busbar current transformer MSQ-30 current transformer 40/5a busbar current transformer
