DM-20 5/5A-300/5A DM current transformer din rail toroidal transformer
DM-20 5/5A-300/5A DM current transformer din rail toroidal transformer
Specifications
Place of Origin :
China
Brand Name :
SUCHEN
Model Number :
CN-DM-20
Usage :
Current
Phase :
Single
Coil Structure :
TOROIDAL
Coil Number :
AUTOTRANSFORMER
Standard: :
IEC60044-1,BS7626,VDE0414
Window size: :
21mm
TYPE: :
DM current transformer
Rated voltage: :
0.72KV
Frequency: :
50/60Hz
Material: :
ABS
CLASS: :
0.5 / 1.0
Packaging Details :
1pcs packed one box, 60pcs packed one carton
Port :
Ningbo
Supply Ability :
10000 Piece/Pieces per Month
Price :
$2.50 - $5.00/pieces
Description
Product Description

DM-20 Current transformer:

Primary current:
Secondary current:
Standard approval:
Maximum voltage:
Frequency:
Rated load:
Class:
Short-time thermal current:
Rated security coefficient:

5A-300A
5A,1A
VDE0414,BS7626,IEC60044-1
0.72/3KV
50-60Hz
1.5VA,2.5VA,5VA

0.5,1.0
Ith=60×Ih
FS<5

DM-20 5/5A-300/5A DM current transformer din rail toroidal transformer

Type Current ratio(A) Rated power(VA) Rated
Class:1 Frequency(Hz)
DM-20 5/5 1.5(10T) 50/60
10/5 1.5(10T) 50/60
15/5 1.5(5T) 50/60
20/5 2.5(5T) 50/60
25/5 2.5(4T) 50/60
30/5 2.5(4T) 50/60
50/5 2.5(2T) 50/60
75/5 1.5 50/60
100/5 2.5 50/60
150/5 3.75 50/60
200/5 5 50/60
250/5 5 50/60
300/5 5 50/60

DM-20 5/5A-300/5A DM current transformer din rail toroidal transformer DM-20 5/5A-300/5A DM current transformer din rail toroidal transformer DM-20 5/5A-300/5A DM current transformer din rail toroidal transformer
