540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
Specifications
Brand Name :
LONGI
Model Number :
LR5-72HPH-540M
Place of Origin :
Jiangxi, China
MOQ :
17050 watts
Price :
$0.25/watts 17050-334799 watts
Supply Ability :
100 Piece/Pieces per Week
Packaging Details :
One piece per carton.
Cell size :
182mmx182mm
Type :
Half Cell
Panel Dimensions :
2300*1120*1243mm
Panel Efficiency :
21.517%
Certificate :
CE
Warranty :
25 Years
Description

LONGI solar 540w Hi-Mo LR5-72HPH 540M Monocrystalline Silicon PV Module

Product Description
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M

Electrical Characteristics STC : AM1.5 1000W/m² 25°C NOCT:AM1.5 800W/m² 20°C 1m/s Test uncertainty for Pmax:土3%

Module Type
LR5-72HPH-540M
LR5-72HPH-545M
 LR5-72HPH-550M LR5-72HPH-555M LR5-72HPH-560M
Testing Condition
STC NOCT
 STC NOCT STC NOCT STC NOCT STC NOCT
Maximum Power (Pmax/W) 540 403.6 545 407.4 550 411.1 555 414.8 560 418.6
Open Circuit Voltage (Voc/V) 49.50 46.54 49.65 46.68 49.80 46.82 49.95 46.97 50.10 47.11
Short Circuit Current (Isc/A) 13.85 11.20 13.92 11.25 13.98 11.31 14.04 11.35 14.10 11.40
Voltage at Maximum Power (Vmp/)
 41.65 38.69 41.80 38.83 41.95 38.97 42.10 39.11 42.25 39.25
Current at Maximum Power (Imp/A)
 12.97 10.43 13.04 10.49 13.12 10.56 13.19 10.61 13.26 10.67
Module Efficiency/(%) 20.9 21.1 21.3 21.5 21.7

Operating Parameters

Operational TemPerature
-40°C - +85°C
Power Output Tolerance 0-3%
Voc and Isc Tolerance 土3%
Maximum System Voltage DC1500V (IEC/UL)
Maximum Series Fuse Rating 25A
Nominal Operating Cell Temperature
45土2°C
Protection Class Class II
Fire Rating UL type 1or2 IEC ClassC
Mechanical Loading
Front Side Maximum Static Loading
5400Pa
Rear Side Maximum Static Loading 2400Pa
Hailstone Test 25mm Hailstone at the speed of 23m/s

Temperature Ratings (STC)

Temperature Coefficientof Isc +0.050%/°C
Temperature Coefficientof Voc -0.265%/°C
Temperature Coefficient of Pmax -0.340%/°C

540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
Specification
item value
place of Origin China Jiangxi
Brand Name LONGI
Model Number LR4-72HPH-550M
Cell size 182mmx182mm
Type Half Cell
Panel Dimensions 2300*1120*1243
Panel Efficiency 21.517%
Certificate CE
Warranty 25 Years

Main Components

Solar Cell

High Anti-PID resistant
Low breakage rate
Color sorting ensure consistent appearance on each module
Service life is as long as 25 years
Translucency of normal luminosity is increased by 2%
Junction box
Long service life
Heat dissipation
IP68 protection level
Conventional standalone edition and engineering custom edition
Quality diode ensures module running safety
Frame
--Conventional frame
--Boost bearing capability and prolong service life
--Serrated-clip design tensile strength
--Seal-lip design glue injection
--Silver or black frames are optional

Packing & Delivery
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
One piece per carton.
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
Company Profile
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
Fuzhou Thinmax is a solar company located at the city Fuzhou which is the capital of Fujian province. We have about 50 office colleagues and 100 factory colleagues. With the professional colleagues and over 10 years experience of dealing with solar system, we are able to provide 100% satisfying service for customers. Not only for the ready products but also the customized products. In order to make the ship more fluently. We have cooperated with more than 20 shipping companies. After customers place the order. We will always choose the cheapest and reliable one to arrange the shipment. When customers have received the items. We have professional technician ready for customers if they have any problems. Please trust Thinmax and give us an opportunity to provide service for you. We won't let you down.
Why Choose Us
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
FAQ
1. who are we?
We are based in Fujian, China, start from 2021,sell to Western Europe(50.00%),Eastern Europe(10.00%),South Asia(5.00%),Southern Europe(5.00%),Northern Europe(5.00%),Eastern Asia(5.00%),Southeast Asia(5.00%),Mid East(5.00%),Oceania(5.00%),Africa(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Solar inverter,Solar panel,Solar system,Battery,Wind system

4. why should you buy from us not from other suppliers?
With more than 10 years experience of dealing with solar system. We provide high quality pre-sale and after-sale service for our customers. We also have factory and professional technicians so we can provide customized product services for customers too.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU；
Accepted Payment Currency:USD,EUR,AUD,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
Recommend Products
Product Description
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
Specification
item
value
Place of Origin
China
Jiangxi
Brand Name
LONGI
Model Number
LR5-72HPH-550M
Cell size
182mmx182mm
Type
Half Cell
Panel Dimensions
2300*1120*1243
Panel Efficiency
21.517%
Certificate
CE
Warranty
25 Years
Packing & Delivery
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
One piece per carton.
Company Profile
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
540w Miniature Solar Panels 182mm Silicon Longi 540w Mono Perc LR5-72HPH 540M
Fuzhou Thinmax is a solar company located at the city Fuzhou which is the capital of Fujian province. We have about 50 office colleagues and 100 factory colleagues. With the professional colleagues and over 10 years experience of dealing with solar system, we are able to provide 100% satisfying service for customers. Not only for the ready products but also the customized products. In order to make the ship more fluently. We have cooperated with more than 20 shipping companies. After customers place the order. We will always choose the cheapest and reliable one to arrange the shipment. When customers have received the items. We have professional technician ready for customers if they have any problems. Please trust Thinmax and give us an opportunity to provide service for you. We won't let you down.
FAQ
1. who are we?
We are based in Fujian, China, start from 2021,sell to Western Europe(50.00%),Eastern Europe(10.00%),South Asia(5.00%),Southern Europe(5.00%),Northern Europe(5.00%),Eastern Asia(5.00%),Southeast Asia(5.00%),Mid East(5.00%),Oceania(5.00%),Africa(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Solar inverter,Solar panel,Solar system,Battery,Wind system

4. why should you buy from us not from other suppliers?
With more than 10 years experience of dealing with solar system. We provide high quality pre-sale and after-sale service for our customers. We also have factory and professional technicians so we can provide customized product services for customers too.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU；
Accepted Payment Currency:USD,EUR,AUD,CNY;
Accepted Payment Type: T/T,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
