Specifications
Place of Origin :
Shenzhen
Brand Name :
Growatt
Model Number :
SPF 3500 ES
Packaging Details :
One piece per carton.
Supply Ability :
100 Piece/Pieces per Week
MOQ :
10 pieces
Price :
$590.00/pieces 10-99 pieces
Input Voltage :
230v
Output Voltage :
230VAC ± 5%
Output Current :
18.4A
Output Frequency :
50Hz/60Hz
Output Type :
Three Phase
Size :
330 x 485 x 135mm
Type :
DC/AC Inverters
Inverter Efficiency :
93%
Certificate :
CE Rohs
Warranty :
5 years
Weight :
15kg
Port :
Ningbo, Shanghai, Shenzhen
Description

Growatt Off grid Solar Inverter SPF 3500 ES 3.5KW Inverter Split Phase 120V 240V

Product Description
Split Phase Hybrid Solar Power Inverter Growatt Off Grid 120V 240V SPF 3500 ES 3.5KW
Datasheet SPF 3500 ES SPF 5000 ES
Battery Voltage 48VDC
Battery Type Lithium/Lead-acid
INVERTER OUTPUT
Rated Power 3500VA/ 3500W 5000VA/ 5000W
Parallel Capability Yes, 6 units maximum
AC Voltage Regulation
(Battery Mode)		 230VAC ± 5% @ 50/60Hz
Surge Power 7000VA 10000VA
Efficiency (Peak) 93%
Waveform Pure sine wave
Transfer Time 10ms typical, 20ms Max
SOLAR CHARGER
Maximum PV Array Power 4500W 6000W
MPPT Range @ Operating Voltage 120VDC ~ 430VDC
Number of Independent MPP Trackers/ Strings Per MPP Tracker 1/1
Maximum PV Array Open Circuit Voltage 450VDC
Maximum Solar Charge Current 80A 100A
AC CHARGER
Charge Current 60A 80A
AC Input Voltage 230 VAC
Selectable Voltage Range 170-280 VAC (For Personal Computers): 90-280 VAC (For Home Appliances)
Frequency Range
inmax Sole		 50Hz/60Hz (Auto sensing)
PHYSICAL
Protection Degree IP20
Dimension (W/H/D) 330/485/135mm 330/485/135mm
Net Weight 11.5kgs 12kgs
OPERATING ENVIRONMENT
Humidity 5% to 95% Relative Humidity(Non-condensing)
Altitude <2000m
Operating Temperature 0°C - 55°C
Storage Temperature -15°C -60°C
