200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor
Specifications
Brand Name :
Alumtimes
Model Number :
AHP-01
Certification :
ISO, CE, SGS
Place of Origin :
China
MOQ :
100 SQM
Price :
US$20-46/SQM
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
30000 SQM per Month
Delivery Time :
18-22 days
Packaging Details :
Plywood Case
Name :
Anodized Aluminum Honeycomb Panel
Size :
1200*2500mm, 1500*4800mm
Max Size :
1650*12000mm, 2000*3000mm
Panel Thickness :
6-100mm
Surface Treatment :
Anodized, PE/PVDF Coated, Printing
Function :
Anti-Static, Antibacterial, Fireproof, Mould-Proof
Usage :
Exterior wall cladding, Signature Board
Skin Materials :
aluminum, fiberglass, zinc, carbon fiber, galvanized sheet
Description

3-200 mm Customized Anodized Fireproof Aluminum honeycomb panel for outdoor application

PRODUCT DESCRIPTION

Aluminum honeycomb panels are sandwich-structured composites with honeycomb cores. They are manufactured by using a variety of different materials, depending on the intended application and required characteristics, from paper or thermoplastics, used for low strength and stiffness for low load applications, to high strength and stiffness for high performance applications, from aluminum or fiber reinforced plastics.

Specification

TOP ALUMINIUM SKINS Thickness (mm):

0,5 - 0,7 - 1 (standard)

Special thickness according to customers’ requirements (such as, 1.5-2.0-3.0mm)

ALUMINUM CORE

Hexagonal cells, Alloy series 3003

Diameter in inches: Ø1/4”, Ø3/8”, Ø1/2”, Ø3/4”

Foil thickness: from 50 to 70 microns

Alloy series 5052 could be customized

BOTTOM ALUMINIUM SKINS Thickness (mm):

0,5 - 0,7- 1 (standard)

Special thickness according to customers’ requirements (such as, 1.5-2.0-3.0mm)

On request: Special alloys, treatments and coating with RAL colors

200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor

Mill finished aluminum honeycomb panel

Colored aluminum honeycomb panels

Fiberglass honeycomb composite panel

Standard Construction:
Face: 0.5-3 mm aluminum sheet
Core: cell size 1/4”,3/8” ,

1/2” ,3/4, aluminum foil 0.04

to 0.08mm
Back: 0.5-3 mm aluminum sheet

Standard Construction:
Face: 0.5-1 mm aluminum sheet
Core: cell size 1/4”,3/8” ,1/2” ,3/4 aluminum foil 0.04 to 0.08mm
Back: 0.5-1 mm aluminum sheet

Standard Construction:
Face: 0.5-1 mm fiberglass impregnated with epoxy resin
Core: cell size 1/4”,3/8” ,1/2” ,3/4, aluminum foil 0.04 to 0.08mm
Back: 0.5-1 mm fiberglass impregnated with epoxy resin

Company prodution capacity: 1000000m2 / year

Company Certificate: ISO9001:2008, ISO14001:2004

WORKSHOP

200mm Anodized Aluminum Honeycomb Composite Panel Fireproof For Outdoor

FEATURES

1. Energy saving, green material: Good thermal and sound insulation & sound insulation, fire resistance.
2. High wind load resistance: High strength & rigidness and stable structure of honeycomb core.
3. Easy installation & low labor cost: Light weight

4. Good decoration: Excellent flatness & wide color selection.

5. Excellent fireproof property

6. Super peeling strength

7. Perfect cold resistance performance

APPLICATION

a. Decoration Materials
b. Wall cladding
c. Building materialHigh-rise building
d. Audio Industry
e. Transportation Industry
f. Furniture Industry
