High Strength Stainless Steel Hex Jam Nuts
This Hex Head Nut has a thread type of coarse, meaning that the threads are widely spaced and designed for quick and easy assembly. The nut is commonly used for fastening applications, making it a versatile addition to any toolbox or workshop.
The weight of this Hex Head Nut is 0.01 Lbs, making it lightweight and easy to handle. Despite its lightweight construction, the nut is incredibly durable and able to withstand the rigors of regular use.
In terms of standards, this Hex Head Nut conforms to ASME B18.2.2, which is a widely recognized standard for fasteners. This means that the nut has been tested and certified to meet certain quality and performance standards, ensuring that it will perform reliably and consistently in a variety of applications.
Overall, the Hex Head Nut is a highly versatile and durable fastener that is well-suited for a range of applications. Its hexagonal shape and external drive type make it easy to use with a variety of tools, while its coarse thread type ensures quick and easy assembly. The nut's lightweight construction and adherence to industry standards make it a reliable and cost-effective choice for any project or application.
d | M8 | M10 | M12 | (M14) | M16 | (M18) | M20 | (M22) | M24 | (M27) | M30 | (M33) | M36 | (M39) | M42 | M45 | ||
P | coarse thread | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 | 2.5 | 2.5 | 3 | 3 | 3.5 | 3.5 | 4 | 4 | 4.5 | 4.5 | |
closely-pitched | 1 | 1 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | ||
closely-pitched | - | 1.25 | 1.5 | - | - | - | 2 | 2 | - | - | - | - | - | - | - | - | ||
m | Nominal Diameter | 6.5 | 8 | 10 | 11 | 13 | 15 | 16 | 18 | 19 | 22 | 24 | 26 | 29 | 31 | 34 | 36 | |
MAX | 6.8 | 8.4 | 10.4 | 11.5 | 13.5 | 15.5 | 16.6 | 18.6 | 19.6 | 22.6 | 24.6 | 26.6 | 29.8 | 31.8 | 34.8 | 36.8 | ||
MIN | 6.2 | 7.6 | 9.6 | 10.5 | 12.5 | 14.5 | 15.4 | 17.4 | 18.4 | 21.4 | 23.4 | 25.4 | 28.2 | 30.2 | 33.2 | 35.2 | ||
h | 2 | 2.5 | 3 | 3.5 | 3.5 | 4.5 | 4.5 | 4.5 | 5 | 6 | 6 | 6 | 8 | 8 | 9 | 9 | ||
s | MAX | 13 | 16 | 18 | 21 | 24 | 27 | 30 | 34 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | |
MIN | 12.73 | 15.73 | 17.73 | 20.67 | 23.67 | 26.16 | 29.16 | 33 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.8 | 68.1 | ||
e | MIN | 14.38 | 17.77 | 20.03 | 23.35 | 26.75 | 29.56 | 32.95 | 35.03 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 72.09 | 76.95 | |
pretightening force/N·m | 11.5 | 22.8 | 36.5 | 65 | 97.2 | 150 | 189.4 | 240 | 296.5 | 470 | 621 | 852 | 1070 | 1400 | 1700 | 2140 |
YB Hex Head Nut is a high-quality fastener product produced in ZheJiang, China. It is made of stainless steel material and certified by ISO90001, ensuring its durability and stability. The hexagonal nut has a model number of Hex Nut under the ASME B18.2.2 standard and is available in stock for immediate delivery. The weight of the nut is 0.01 Lbs, and it comes in a package quantity of 100 units.
YB Hex Head Nut is a versatile product that can be used in various industries. Its hexagon head design provides excellent grip and stability, making it perfect for heavy-duty applications. These nuts are commonly used in construction, machinery, automotive, and electrical industries.
The Hexagon Head Nut is ideal for use in scenarios where a reliable and secure fastening mechanism is required. It is designed to resist loosening due to vibration or torque, ensuring maximum safety and stability. The product is available in large quantities, with a minimum order quantity of 5000 units and a supply ability of 500ton/month.
YB Hex Head Nut is packaged in carton boxes to ensure safe and damage-free transportation. The delivery time for the product ranges from 7-20 days, and payment terms are negotiable through the T/T method.
In conclusion, the YB Hex Head Nut is a reliable and cost-effective fastener product that can be used in a wide range of industries. Its hexagonal head design, ASME B18.2.2 standard, and stainless steel material make it durable and stable. With a minimum order quantity of 5000 units, negotiable pricing, and fast delivery, this product is an excellent investment for any industry that requires a reliable and secure fastening solution.
