2ply Wires Fluting Paper Roll Making Machine 3200mm Width
2ply Wires Fluting Paper Roll Making Machine 3200mm Width
2ply Wires Fluting Paper Roll Making Machine 3200mm Width
2ply Wires Fluting Paper Roll Making Machine 3200mm Width
2ply Wires Fluting Paper Roll Making Machine 3200mm Width
2ply Wires Fluting Paper Roll Making Machine 3200mm Width
Specifications
Brand Name :
PingAn
Model Number :
3200mm
Certification :
ISO9001:2008
Place of Origin :
China
MOQ :
1set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
10sets/year
Delivery Time :
8month
Packaging Details :
wooden case
Machine wire :
2ply wires (top wire + bottom wire)
Press section :
K press ++ jumbo press
Headbox type :
Air cushion type
Sizing machine :
include
Headbox brand :
Xi'an Weiya
Item :
3200 2ply Wire Paper Making Machinery
Description


Description

This Paper Making Machine And Paper Machinery In PINGAN COMPANY is specially designed to produce high grade fluting paper and kraft paper. The wire section is composed of :

1- 2sets air cushion headbox

2- forming table

3- white water pan

4- forming plate

5- dewatering plate

6- wet suction box

7- high and low suction box

8- breast roll, breast roll

9- support and lifting device

10- vacuum couch roll

11- wire driving roll

12- wire leading roll

13- doctor

14- shower

15- trim cutter, trim squirt

16- tensioner, corrector.

The fourdrinier is polyester forming wire and cantilever type wire-changing device. The jack on the operation side. Wire design tension: 7KN/m. Elongation is 1.5%.

Forming section rolls in this paper making machine

1 Breast roll and bearing 2sets
2 Guide rolls 8sets
3 First wire drive roll 1set
4 Wire drive roll 1set
5 Compound roll 1set
6 Vacuum couch roll 1set

1ply wire paper making machine headbox material description

Top lip plate: Material is stainless steel 316L
Bottom lip plate: Material is stainless steel 316L

Side wall: Material is stainless steel 304

Back wall: Material is stainless steel 304
Front wall: Material is stainless steel 304
Base: Material is stainless steel 304
Tope cover: Material is stainless steel 304

Cone tube: Material is stainless steel 304

2ply Wires Fluting Paper Roll Making Machine 3200mm Width
