Automatic Hologram Film Embossing Machine For Pet,PvcOopp Film

Performance and use:

This machine has imported foreign advanced membrane press technology and integrated design with many years of production experience of membrane press. This machine is suitable for holographic laser holographic laser high quality PET rainbow pigment mask, light column membrane, hot stamping film and transfer film. The molding thickness is 12-200um. The working principle is to heat and transfer the holographic laser pictures and texts pre-duplicated on nickel sheets onto thin film materials.

The machine can effectively solve the common black spot defect of plate stitching on the film surface, greatly improve the utilization rate of materials and reduce the production cost, stabilize the continuous film pressure, and make the laser vision effect clearer.

1. Vector closed-loop control is implemented by Mitsubishi Tension Controller and Mitsubishi A700 series frequency conversion, and seamless control is implemented by PID control of optical fiber sensor.

2. Panasonic PLC and Veron HMI are used for automatic control, which is easy to operate and practical.

3. The heating system is equipped with WJD-36 external circulation heater. The machine uses oil temperature to heat and heat conducting oil to close the cycle.

4. With high-temperature heat conduction system, the temperature can be adjusted from 30 to 200 degrees (Fuji can only control temperature), and the heating speed is fast (generally it takes 20 minutes to warm from 30 to 200 degrees).

5. Equipped with automatic oil injection and blowing system, the replacement of plate rollers is simple and fast, saving the time of changing plate rollers (usually 20 minutes) and improving production efficiency.

6. Roller-type pulse counting touch screen is used to make electronic display high-speed and accurate.
