5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine
5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine
5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine
5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine
5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine
5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine
Specifications
Brand Name :
FECT
Model Number :
PF-450
Place of Origin :
Henan, China
MOQ :
1 set
Price :
USD$ 13,968/ set
Payment Terms :
30% T/T as deposit in advance, the balance by T/T after production
Supply Ability :
50 sets per month
Delivery Time :
Within 35 days after deposit received
Packaging Details :
Export-standard and sea-worthy wooden case.
Name :
5-20 bag/min Automatic water cup plastic cup paper cup packing machine
Type :
PF -450 Follow packing machine
Film max-width :
450mm
Film thickness :
0.02-0.06mm
Packing speed :
5-20（bag/min）
Length :
200-600mm
Description

5-20 bag/min Automatic water cup plastic cup paper cup packing machine

♦ Advantages ♦

  • The PF450 Paper Cup packing Machine, it can count from 1 to 100(the counting range)of the cups and then pack them.
  • The machine line also been controlled by PLC system and servo motor. And it is very easy to understand and operate.
  • The best advantage is the way of delivery, it is Bele”V”. it can improve the precision of counting and it can make the cups not been worn down.
  • The hole-punching machine has different range of the diameter, customers can choose the needing diameter as they need.
  • The film delivering is under the machine, the thickness of the film with 0.03mm will been no problem.

♦Application♦

PF450 Paper Cup packing Machine is It used for counting, packing disposable (one-off)cups.

Packaging:

Stable wooden package protects machine from strike and damage.
Wound plastic film keeps machine out of damp and corrosion.
Fumigation-free package helps the smooth customs clearance.
The big size machine will be fixed in container without package.

Quality Guarantee: One year warranty and lifelong technical service, Inspection before delivery is available. The above clause is ONLY effective under the machine is being properly used, any artificial misuse or destroy purposely is not within the limit of Quality Guarantee.

Installation and Debugging: we can send technician for installation and training at the cost of buyer (visa, round tickets, eating, accommodation in his country and salary 100 USD /day).

♦Technical Specification♦

Type PF -450 Follow packing machine
Film max-width 450mm
Film thickness 0.02-0.06mm
Packing speed 5-20(bag/min)
Length 200-600mm
Height ≤90mm
Counting packing machine dimensions 3500mm×2050×1350mm
Power 2.8kw
Type PF 450 Auto counting machine
Cups diameter Φ60-Φ80mm
Number of single counting 25pcs
Counting speed 200pcs/min
Way of delivery(choose) 6500×1050×1350mm
Counting packing machine dimensions 6500×1050×1350 mm
Power 2.8kw
Weight 1200kg

♦Configuration list♦

Item Model QTY Brand
PLC FP-XU32T 1 PCS PANASONIC
TOUCH SCREEN TPC7012 1 PCS BEIJING KUNLUNTONGTAI
AIR SWITCH DZ47-63-C10 5 PCS CHINT
SWITCHING POWER SUPPLY S-50-24 1 PCS TAIWAN MINGWEI
TEMPERATURE CONTROLLER XMTG-9081 2 PCS ZHEJIANG YATAI
SOLID STATE RELAY 220D25 2 PCS YANGMING, TAIWAN
FEEDING SERVO / FEEDING SERVO D75AA-1000 1 PCS INOVANCE
EMERGENCY STOP SWITCH 1 PCS SCHNEIDER
START SWITCH 1 PCS SCHNEIDER
STOP SWITCH 1 PCS SCHNEIDER
PHOTOELECTRIC SWITCH Z3M-TB22 1 PCS ZHEJIANG JULONG
COUNTING PHOTOELECTRIC 491 4 PCS PANASONIC

5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine5-20 Pcs/Min Automatic Paper Cup Packing Machine Plastic Water Glass Packing Machine
