PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min
Specifications
Brand Name :
XINYUN
Model Number :
XY-NGU-21C
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD 53000 Set
Payment Terms :
T/T
Delivery Time :
Within 70 days after receipt of the deposit.
Packaging Details :
Wooden pallets or wooden boxes
Counting Unit :
Electronic Counting
Production Speed :
8-12bags/min
Control System :
PLC
Safety Device :
Emergency Stop Button, Safety Guard
Operator Interface :
Touch Screen
Packing Material :
Double-sided heat sealing membrane such as CPP, PE, CPP
Description

XY-NGU-21C Best Price Automatic Pocket Paper Tissue Machine Production Line

PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min

Machines Including:

Pocket tissue(handkerchief tissue) folding machine with separator

Automatic pocket tissue (handkerchief tissue) packing machine

Automatic pocket tissue(handkerchief tissue) wrapping machine

Pocket tissue (handkerchief tissue) folding machine with separator

PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min

Main Technical Parameters:

Speed of the separator

60 bags/min

Speed control

Frequency converter

Raw material

13-25gm 1-3plies

Outer Dia. of jumbo roll

max. 1500mm

Embossing unit

single embossing (steel to rubber, stamp designed by user)

Vacuum pump

5.5Kw, 380V, 50Hz

Production speed

600PCS/min (controlled by frequency converter)

Finished products unfold size

210*210mm

Finished products folded size

102*52mm and 72*52mm

Power

0.75kw, 380v, 50Hz

Overall size

3851×650×1380mm(L×W×H)

Over weight

about 1T

Automatic pocket tissue (handkerchief tissue) packing machine

PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min

Main Technical Parameters:

Size of finished product: standard size

L=102mm, W=52mm, H=22-26mm

Mini size:L=72mm, W=52mm, H=22-26mm

Packing size(L*W*H)

(70-110)*(50-55)*(20-28)mm

Machine speed

105bags/min

Stable speed

90bags/min

Heating power

3.5Kw, 220V, 50Hz

Drive power

1.5Kw, 380V, 50Hz

Air pressure

0.6Mpa (user supplied)

Step Motor

0.38Kw, 380V, 50Hz

Machine size

2840*2650*1720mm (L*W*H)

Machine weight

1.5T

Automatic pocket tissue (handkerchief tissue) wrapping machine (single channel)

PLC Automatic Pocket Paper Tissue Machine Production Line 8-12bags/min

Main Technical Parameters:

Size of finished product

5*2(standard size:260*102*44/52mm,mini size:260*72*44/52mm)

Machine speed

8-12bags/min

Heating power

1.78Kw, 380V, 50Hz

Drive power

1.5Kw, 380V, 50Hz

Air pressure

0.6Mpa (user supplied)

Step Motor

0.38Kw, 380V, 50Hz

Machine weight

1.4T

Machine size

2500*2350*1550mm (L*W*H)

FAQ:
Q: Are you trading company or manufacturer?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 60-90 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? Is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
