Specifications
Brand Name :
Xinyun
Model Number :
XY-GU-A-B
Certification :
CE
Place of Origin :
Quanzhou
MOQ :
1 set
Price :
USD 100000 Set
Payment Terms :
T/T, L/C
Supply Ability :
80 sets per year
Delivery Time :
60 days
Packaging Details :
In standard export packing wooden pallet
Production Speed :
14-18bags/min
Machines size :
48000*2000*1350mm
Size of finished product :
L（180-400）* W（260-400）*H(70-100)mm
Packing method :
Prefabricated bag
Packing type(bag) :
One line：1*3,1*4,1*5; Two line: 2*3，2*4，2*5
The width of jumbo roll paper :
1400mm
Diameter of jumbo roll paper :
1100mm
Daily Output (8 hours :
2000-3000Kg
Folded size of finished products :
95*(120-210)±2mm
Unfold size of finished products :
190*210±2mm
Embossing unit :
Steel to steel full embossing, Steel to steel edge embossing ,independent pneumatic regulation
Description

XY-GU-A-B Good Quality V Fold Facial Tissue Paper Production Line For Manufacturing Plants

Outline:

The automatic facial tissue production line consists of a facial tissue folding machine, a single-channel log saw cutting machine, and a single-bag packing machine. The entire production process, from raw materials to finished products, runs smoothly and stably.

This production line features a high degree of automation, significantly reducing labor costs and minimizing labor intensity. It is the ideal choice for efficient tissue product manufacturing.

V Fold Facial Tissue Paper Production Line For Manufacturing Plants

XY-GU-20A Automatic V fold facial tissue making machine

Product Description

XY-GU-20A facial tissue making machine working flow :The jumbo rolls which have been slit into the desired width are cut by the slitting cylinders, and reciprocal folded into a sheet of rectangular or square facial tissue. This machine adopts independent servo motor drive ,and automatic paper tension control. It features of high speed ,nice folding and easy operation .

V Fold Facial Tissue Paper Production Line For Manufacturing Plants

Parameter

Machine model XY-GU-20A
Folded size of finished products 95*(120-210)±2mm
Unfold size of finished products 190*210±2mm
The width of jumbo roll paper 1400mm
Diameter of jumbo roll paper 1100mm
Diameter of jumbo roll paper inner core 76.2mm
Daily Output (8 hours) 2000-3000Kg
Embossing unit Steel to steel full embossing, Steel to steel edge embossing ,independent pneumatic regulation
Power 5.5KW Main motor
1.5KW(2 sets) Jumbo roll paper stand
Vacuum suction unit 18.5KW Fan
Pneumatic system 3 HP air compressor ,mini pressure 5kg/cm2PA
Driving system Timing belt
Overall dimension 7950*2500*1850mm
Weight 6.0T

XY-GU-281 High-speed facial tissue cutting machine for manufacturing plants

Product Description

XY-GU-281 paper cutting machine is used to automatically cut off a row folded and round roll paper towel products, such as the removable tissue or toilet roll paper. The whole machine adopts servo drive technology and frequency control of motor speed and enhance the stability of paper cutting, and improves the cutting precision of tissue and to cut off the end face flat . Cutting length within the scope of the machine allows arbitrary adjustable. Fixed automatic knife grinding wheel Angle, ensure the quality of the sharpening knife. Knife grinding place often blow compressed air for cooling, and can match the special cooling fluid.

V Fold Facial Tissue Paper Production Line For Manufacturing Plants

Parameter

Designation Parameter values
The length of unfinished products minimum 500mm(or, mini 5lines)
The Height of finished product 30~130mm
Production Speed 20~150cuts/min
Operating speed 20~120cut/min
Round blade outer diameter Φ610mm
Paper cutting circular knife top speed 980R/min
Finished products specification 70~300mm
Paper width 70~110mm
Cutting Length 70~300mm
Left-over Length 20~65mm
Power 11KW
Power supply 380V 50Hz
Air pressure 0.5~0.8MPa
Machine Size 4600*1700*2500mm
weight 2300~2600kg

XY-BT-298 Automatic Facial Tissue Paper Packing Machine

Product Description

The high-speed fully automatic facial tissue single wrapping machine is designed for automatically packing V-fold hand towels, facial tissues, and napkins. The tissue arraying and feeding processes use variable frequency control. Packaging actions such as hole punching, film pulling and positioning, film cutting, and tissue center feeding are all controlled by servo motors.

This machine offers several advantages, including a complete operational configuration, high efficiency, ease of use, a wide range of size applications, quick size changes, easy maintenance, and low operating costs.

V Fold Facial Tissue Paper Production Line For Manufacturing Plants

Parameter

Max. design mechanical speed Max. 80 bags/min
Max. stable operation speed 65 bags/min
Tissue length range (finished product) 120 mm- 210 mm
Tissue height range(finished product) 40 mm- 100 mm
Tissue width range(finished product) 90 mm- 105 mm
Spare parts for change size 3 sets
Machine size(L*W*H) 4600*3620*1770mm
Machine weight About 3000KG

XY-GU-26B Semi-automatic medium bag facial tissue packing machine

Product Description

This machine is suitable for soft packing of middle package, belt automatic blanking flip device, single row double adjustable, the activities of the head to facilitate the workers bagging, automatic delivery of finished products, provincial efficient. Double head out of the material only one person bagging.

V Fold Facial Tissue Paper Production Line For Manufacturing Plants

Parameter

Speed 14-18bags/min
Packing size(mm) one line

L(180-400)*

W(130-200)mm
Two lines

L(180-400)*

W(260-400)mm
Thickness H:70-100mm
Packing type(bag)

One line:1*3,1*4,1*5;

Two line: 2*3,2*4,2*5
Packing method Prefabricated bag
Feeding control Automatic feeding
Bagging method Manual
