Specifications
Brand Name :
PRINTYOUNG
Model Number :
ZH - 800G
Certification :
CE
Place of Origin :
China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 sets per month
Delivery Time :
30 working days after received your payment
Packaging Details :
Neutral packaging, suitable for shipping in a solid iron frame composite box or fumigation wooden box, to adapt to climate change, Fang Lin, moisture, mold, shock, rust.
Type :
Paper box making machine
Processing type :
Gluing machine
Box forming :
Straight line prefold line bottom lock
Paper weight :
210-660gsm
Driven type :
Electric
Speed :
0-220m/min
Application :
Food Medical
Weight :
1300kg
Description

Crash Lock Bottom Folder Gluer Machine With Remote Control Airplanes

Quick Details

ZH-800G/880G/1000G is the latest multi-functional crash lock folder gluer; it made indelible contributions to the firld of folder gluer. It comblnes a variety of folder gluer features, the general-paste, pre-folded edges with crash lock bottom. It's powerful, widely usage, easy operating and adjusting boxes. Especially for the current packaging and printing industry-competitive business, the delivery of the tight schedule offers great convinience, so the packaging equipment is ideal for the printing industry. It is widely used in processing medecine box, wine box, cosmetics box, electric appliances, packing box, etc. ZH-G was awarded two patents.

Features

Line Speed:0-220m/min adjustable

Paperboard:210-660gsm paperboard

Box forming;both sides prefold,fold from either side,either sdide glue,bottom glue.

Paper board feeding:Automatic

way of folding:1st,2nd and 4th fold 180°,3rd folds 135°

Gluing:four stations,2 upper stations,2 lower stations.Each lower station has a grindingwheel for cleaning UV varnish and ink off the flap before gluing.

Glue type:water solvable

Weight:1110KG/1300KG

Dimension:8000*900*1300(mm)

Auto Counting Range:0---999999 No.with batching facility

New Features

Pressure table : Independent speed control,With Cover

Trombone : Wire-controlled jogging to change fixed wallboard

The place of paper board feeding is embedded

Bale no disassembly,long service period

Crash Lock Bottom Folder Gluer Machine With Remote Control Airplanes 0-220m / min Crash Lock Bottom Folder Gluer Machine With Remote Control Airplanes 0-220m / min

line box crash lock bottom

Model Box type (A Max) (A Min) (B Max) (B Min) (C Max) (C Min) (D Max) (E Min)
ZH-800G Straight line box(I) 560 106 50 65 270 50 7 6
Pre-fold box(I) 560 180 500 65 270 90 10 6
Crash lock bottom box(I) 560 160 500 65 270 80 40 6
ZH-880G Straight line box(I) 660 110 500 65 320 50 7 6
Pre-fold box(I) 660 180 500 65 320 50 7 6
Crash lock bottom box(I) 660 160 500 65 320 80 50 6
ZH-1000G Straight line box(I) 760 130 600 80 370 60 10 8
Pre-fold box(I) 760 180 600 80 370 90 15 8
Crash lock bottom box(I) 760 180 600 80 370 90 60 8
