Specifications
Brand Name :
PRINTYOUNG
Model Number :
CHM-A4-2
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
US 165000 Set
Payment Terms :
L/C, T/T
Supply Ability :
10 Set/Sets per Month
Delivery Time :
60 days
Packaging Details :
Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions. A full set of maintenance and operation manuals is included.
Voltage :
380V
Production Capacity :
0-250 m/min
Max. workable Width :
850 mm
Paper Width :
Gross width 850 mm, net width 840mm
Cutting Numbers :
2 cutting-A4 210mm (width)
Paper Roll's Diameter :
Max.1400mm. Min.600mm
Paper Core's Diameter :
3"(76.2mm)or according to the clients' demand
Paper Weight :
60-100 gsm
Sheet Length :
297 mm
Ream Amount :
500 sheets Max. Height: 45-55mm
Production Speed :
Max 0-250 m/min
Max. Numbers of Cutting :
Max841/min
Output of the Ream :
Max 13 reams/min
Description
CHM-A4-2 Compact A4 Cut Size Sheeting and Packaging Production Line
Technical Parameters
CHM-A4-2(pocket) Cut Size Sheeting Machine
Paper Width
Gross width 850 mm,net width 840mm
Cutting Numbers
2 cutting-A4 210 mm (width)
Paper Roll’s Diameter
Max.Ф1400mm. Min.Ф600mm
Paper Core’s Diameter
3”(76.2mm)or according to the clients’ demand
Packing Paper Grade
High-grade copy paper;High-grade office paper;
High grade Free Wood paper etc.
Paper Weight
60-100 g/m²
Sheet Length
297mm(specially design for A4 paper,the cutting length is 297mm)
Ream Amount
500 sheets Max. Height: 45-55mm
Production Speed
Max 0-250 m/min (depends on different paper quality)
Max. Numbers of Cutting
Max 841/min
Output of the Ream
Max 13 reams/min
Load of Cutting
100 g/m²(1×100g/m²)
Cutting Accuracy
±0.2mm
Cutting Condition
No variation of the speed,no break,
cut all the paper at one time and need the eligible paper
Main Power Supply
3*380 V / 50HZ
Voltage
220V AC /24V DC
Power
22 KW
Air Consumption
200 NL/min
Air Pressure
6 bar
Edge Cutting
5~15mm*2
Safety Standard
Design according the safety standard of China

CHM-A4B Wrapping Machine
Paper Width
Gross width:310mm;Net width:297mm
Ream Packing High
Max 55mm;Min 45mm
Packing Roll Dia.
Max.1000mm;Min.200mm
Packing Roll Width
560 mm
Packing Sheets Weight
70-100 g/m²
Packing Sheets Grade
high-grade copy paper,high-grade office paper,
high-grade offset paper etc.
Design Speed
Max 50 reams/min
Operation Speed
Max 35 reams/min
Packing Condition
no speed variations,no breaks,
cut all the paper at one time and qualified packing paper.
Driving
AC Servo Precision Control
Main Power Supply
3*380V / 50HZ (or as required)
Voltage
220 V AC / 24V DC (or as required)
Power
18 KW
Compressing Air Consumption
300 NL/min
Air Compressor
6 bar
Configuration

Unwind Stand(1Sets=2Rolls)

A-1 Type:CHM-A4-2
1)Machine Type:Each machine table can take 2 sets of shaftless paper rack.
2)Diameter of the paper roll:Max. Ф1400mm
3)Width of the paper roll:Max. Ф850mm
4)Paper rack’s material:Steel
5)Clutch device:Pneumatic Braker and control
6)Clip arm’s adjustment:Manual adjust by oil pressure
7)Paper core demanding:3”(76.2mm) air expansion shaft chuck

Automatic Tension Control System

When the paper through inductor, that automatic feedback to the PLC control system to increase brake load, increase or reduce the tension that control the paper tension automatically.

High Precision Cutting Knife System

1)Upper and lower knives are rotary make the cutting accuracy is very precision.
2)Anti-curve device Include one set of square bar and steel wheel.When the curve paper through paper edge unit that can adjust the paper square and let it flat.
3)5 sets slitting knives
Upper slitting knife take by air pressure and spring.Lower knife connect with bear drive(the diameter is Ф180mm)and move with spring.The upper and lower round knife is made by SKH.The lower slitting knife (diameter is Ф202mm) and drive with in-phase belts.The lower slitting knife is 5 groups,each group have two knife edge.
4)Paper feeding wheel
Upper wheel:Ф200*550mm (rubber covered)
Lower wheel:Ф400*550mm (anti-glide)
5)Cutting knife group
Upper cutting knife:1 pcs 550mm
Lower cutting knife:1 pcs 550mm
6)Driving group(High precision bear and belt drive)
7)Main driving motor group

Transporting System

1)Transporting by level and overlapping device
2)High speed transporting belt and press wheel.Upper and lower transport belt corresponding pressure paper,automatic tension and close system.
3)Static removal device(Include static removal bar and Negative ion generator)

Paper Collecting System

1)Automatic device for paper stack up and down
2)Jogging device and clap paper tidy.Control by air vat,when design sheet,the cylinder up and down by cut paper bar.After transport paper to belt, transport to the pack table cross.

Accessories

Cross cutting knifes:1 set 550mm Material:compounding of tungsten steel
Upper slitting knife:5 pcs Ф180mm Material:SKH
Lower slitting knife:5 pcs Ф202mm Material: SKH
Q1.Are you a manufacturer or a trading company?
A:Our shanghai office is mainly doing export.We have our own factory in Wenzhou,Zhejiang Province.
Q2.What is the machine warranty?
A:One year.After the warranty,we still provide technical support to buyer at low cost.
Q3.What is the production time while placing order?
A:Normally about 10-20 days.
Q4.What is the delivery time?
A:15-30days after deposit.
Q5.Can your company handle shipping for customers?
A:Yes,just give us destination sea port or container yard.
Q6.Does the packing strong?
A:Yes.Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions.A full set of maintenance and operation manuals is included.
Q7.How about the machine installation and training?
A:1)We provide training in our factory for free;
2)We can send technicians (engineers) to your factory for installation and training.
You shall pay the round trip air fare and accommodations,plus each technician charges USD100/per day.
Q8.Do you have machines in stock?
A:For standard model,we have a large quantity in stock.For special model,we need 20-30 days to produce it for you.
Q9.How can you assure the machines’ quality?
A:Each machine will be test running at least 24 hours before delivery to assure the quality.
And during the warranty,we will give spare parts for free if machine has any problem.
Q10.Do you inspect machines or test running before packing?
A:Of course we do.We have QC department to debug the machine before packing.
If you want to use specific material to do the test running,you need to pay for the cost of the material.
Q11.What’s the payment term?
A:T/T 30% in advance,the balance shall be paid before delivery.We also accept payment by West Union or L/C at sight.
Q12.Do you accept factory visiting?
A:Warmly welcome for your visiting.
Q13.How many years are you in printing field?
A:The Shanghai company since in 2008,the factory is more than 25years.
Q14.How many clients do you have?
A:We have sold our machines to about 60 countries.We have agents in South Africa,Morocco and Italy.
