1100CS Automatic High Speed Four and Six Corner Carton Box Folder Gluer Machine

Feature Introduction

Independently motorized motor control, simultaneous feeding mode with the main motor.Feeder section equipped with three pieces feeding knife, adjust the asymmetrical lengths as per the box sample.Rail width can be horizontally adjusted and set by seven pieces 30mm thickened feeding belt and 10mm metal board.Embossing drive wheel guide the feeding section belt, side feed gates in the right and left are adjustable according to the products.Vibration device coordinate with motor which helps machine consecutive and automatic feeding quick and simply. Feeder section can stack 400MM height paper board.

The paper board sent from feeder section will be corrected by aligner section to ensure transmission accurately.Pressing drive pressure can be adjusted up and down to accommodate different paperboard thickness.

Special first folding line pre-fold 180°. third line 170° ,Which perfectly meeting the requirements of automatic packaging industry.

Complete set of folding hooks and helixes to fold the front flaps of the blank smoothly and accurately. Bottom lock section with three board,which can better apply to the large rash lock bottom boxforming.Sectional-type upper belt board with special design, which can be adjusted according to the products type ,no need to tension belt.

Optional lower gluing tank in the right and left side with large volume.Electronic upper gluing system by guns.Optional lower gluing tank in the right and left side with large volume.

Up and down belt can be adjusted separately.Equipped with photo electronic counting device and kicking paper device, which can press the paper after accounting and make it easy to pack . Also equipped with feeding paper inspection device.

Equipped with special additional sponge belt for the press of boxes valley part.Upper section moves back and forward, allowing for different box length.Pneumatic pressure regulator

Machine using motorized and united electronic back folding system with intelligent servo motor technology

Two driven shafts allow a precise fold of the rear flaps. Easy to setup through the main touch screen.

Equipped with three guns, convenient in the production of 4/6 corner box and various special-shaped box, gluing quickly and accurately sizing.
