High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
Specifications
Brand Name :
Particle
Model Number :
NVD3000
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T
Lens focal length :
70mm
Customized Support :
OED,ODM,OBM
Defog :
Support
Infrared detection resolution :
640×512@12um
Product Category :
Multifunctional Handheld Infrared Night Vision
IR Detector :
640×512@12um
Focal Length :
105mm
Visible FOV :
≥3.2°×2.4°
Infrared Recognition Distance :
Mid-Size Vehicle：≥2.8km; Standing Man：≥1km
Infrared Detector :
640×512@12um
Infrared Focal Length :
70mm
FOV :
≥6.3°×5.0°
Visible Light Recognition Distance :
Mid-Size Vehicle：≥6.6km；Standing Man：≥3km
Visible Light Resolution :
2592×1944@2.7um
Visible Light Focal Length :
105mm
Visible Light Focal Length Adaptation Range :
50m～∞
Visible Light :
≥3.2°×2.4°
Laser Ranging :
（1）Minimum Range：≤50m； （2）Maximum Range：≥6km； （3）Precision：≤2m； （4）Accurate Rate：≥98%； （5）Repeat Frequency：≥0.5Hz
Laser Ranging Logic :
Select to display the first or last target capability measured
Laser Ranging Wavelength :
Human eye safety band
Positioning Precision :
≤7m（CEP），≤10m（PE）
Magnetic Azimuth :
≤0.5°（RMS）
Target Positioning Accuracy :
at 2km of the distance，≤20m（CEP）
Diopter :
-4SD～+4SD
Digital zoom :
1×~4×
Working Time（Room temperature） :
≥10h
Memory Storage :
32G
Operating Temperature :
-40℃～+55℃
IP Grade :
IP67
Weight :
≤1.6kg
External Interface Data :
USB
External Interface Video :
PAL
Communication :
RS232
Interface Type: :
Reserved Picatinny Rail
Price :
$17,000
Description

High Resolution Uncooled Thermal Imaging Monocular for Infrared Detection

APPLICATIONS
The NVD3000 binocular handheld uncooled thermal imaging telescope is designed to cater to a variety of user needs across different scenarios. It boasts a built-in thermal imaging detector and visible light sensor, enabling users to switch between thermal and visible light images with ease. Integrated with satellite positioning, laser ranging modules, and an electronic compass, it provides precise self-positioning and target positioning data. Ideal for field observation, surveillance, and gathering target location information, the NVD3000 is perfect for target identification and search guidance.

Technical Parameters:

Product model NVD3000
Infrared
Mid-Size Vehicle ≥2.8km
Standing Man ≥1km
Infrared detection resolution 640×512@12um
Lens focal length 70mm
Infrared FOV ≥6.3°×5.0°
Visible Light
Mid-Size Vehicle ≥6.6km
Standing Man ≥3km
Resolution 2592×1944@2.7um
Focal Length 105mm
Focal Length Adaptation Range 50m～∞
Visible FOV ≥3.2°×2.4°
Defog Support
Laser Ranging
Minimum Range ≤50m；
Maximum Range ≥6km；
Precision ≤2m；
Repeat Frequency ≥0.5Hz；
Ranging Logic Select to display the first or last target capability measured；
Laser Wavelength Human eye safety band；
Positioning Orientation
Positioning Precision ≤7m(CEP),≤10m(PE)
Magnetic Azimuth ≤0.5°(RMS)
Target Positioning Accuracy at 2km of the distance,≤20m(CEP)
Other
Diopter -4SD～+4SD；
Digital zoom 1×~4×；
Working Time(Room temperature ≥10h
Memory Storage 32G；
Operating Temperature -40℃～+55℃；
IP Grade IP67；
Weight ≤1.6kg；

* These parameters are for illustrative purposes only and are subject to change without prior notice due to product updates and improvements.

NVD 3000 Details:

High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection

► Thermal imaging observation mode and visible light observation mode can be switched with one click, and screen brightness, contrast, image quality enhancement, etc. can be personalized
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
► Supports guided search function after entering target coordinates
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
► PIP
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
► Supports fog penetration function in visible light (color, black and white) observation mode
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
► Laser ranging and real-time display of distance, longitude, latitude, elevation and other data of the measured target
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
► Relative ranging function supports relative distance calculation between targets
High Resolution Uncooled Thermal Imaging Monocular For Infrared Detection
