Soundproof Dividers Conference Room Movable Partition Wall

Description:

Movable sound-proof partition walls are characterized by modular elements having high acoustic insulation up to an index of 53 dB certified by an accredited laboratory. They are easily stored and slide quietly along guide rails fixed only into the ceiling. Designed to harmonize with the existing architectural style they can reach any length and up to 12 m. in height with covering in a choice of materials and finish. High-level technology guarantees quality and reliability while offering the ideal solution for a rapid, physical and acoustic division of areas destined to host large events, meetings, workshops, video conferences and training sessions.

Feature:

Individual panels that can be stored away for maximum space utilization.
Operable top and bottom seals for effortless operation.
Isolated aluminium frame construction for enhanced acoustics.
High performance multiple in fill's for maximum sound attenuation.
Unique track and carrier system ensuring quiet and easy operation.
Numerous panel stacking options for complete flexibility.
No floor track ensuring obstruction free threshold.
Three panel sizes to accommodate a wide range of acoustic requirements .
Extensive range of surface finishes can be applied.

Advantage:

Wall panels are of double skin construction with a robust internal aluminium frame. The panel faces are not 'hard' fixed to the frame and therefore when sound waves 'hit' one side of the wall the vibration caused is not directly transferred to the opposite face. Aluminium edge profiles may be CONCEALED, OR EXPOSED to provide a trim.

Heavy duty rubber gaskets are fitted to the panel profiles ensuring maximum acoustic sealing to all surrounding surfaces.

The highest levels of sound reduction are achieved by introducing rubberized bitumen membranes and mineral wool insulation to the core of each panel.

The rapid action mechanism, which operates the retractable seals, is designed to exert sufficient pressure to achieve the high levels of sound reduction offered. The retractable seals are designed to tolerate deviations in floor level and the deflections of supporting structures. The tolerance limit is evaluated for each individual application.

Technical information:

Design details:

Layouts that respect the end user.
Hundreds of designer wall coverings to choose from: carpet, vinyl, fabric, laminate, wood, steel, glass, mural, and paint.
Any visible part can be customized to achieve your look.
Acoustical design assistance.
Curtain Walls, Partition, Operable, Glass, Air walls, Breakout, Meeting Room Dividers, Flexible Space, Banquet Room, Exhibit Space.

Application:

All of our operable wall systems are individually tailored to your exact requirements and are therefore the perfect solution when high acoustic performance and a feeling of quality are the main priorities.

Whilst widely used within hotel banqueting suites and conference centers with large muti-functional spaces they are also ideally suited for use within offices to give added flexibility to meeting, training and conference rooms.

The individual panels can be easily operated by handle because they are ceiling hung there is no potential obstruction from floor track to worry about giving maximum flexibility on how the space is used.

Our service:

Smooth out cosmetic and surface damage.
Replacement of seals and activation hardware.
Reconditioning of trolleys, track, intersections and switches.
Relocation and rerouting of existing operable walls.
Demolish and replace with new acoustical partitions.
Improve soundproofing of partition walls and building envelope.
Repair and adjust to factory specification.
