Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish
Specifications
Brand Name :
BUNGE
Model Number :
85 mm acoustic partition walls
Certification :
ASTM E90
Place of Origin :
Guangzhou,China
MOQ :
No MOQ
Price :
US $78-108 per square meter.
Payment Terms :
T/T, Western Union
Supply Ability :
5000 square meters per month
Delivery Time :
7-15 days
Packaging Details :
Paper carton,outside with wooden boxes.
Product name :
Acoustic partition walls
Panel material :
MDF+Laminate
Open style :
Sliding
Feature :
Acoustic,sound proofing
Thickness :
85 mm(3 1/4 inch)
Size :
Accept customized
Iner Material :
Soundproof cotton
Colors :
Can be customized
Sample :
Free
Description

MDF Laminate Finish Acoustic Operable Partitions Sliding Foldable Partition Walls Panels

Acoustic partition walls details

  • Material: MDF, glass fiber, aluminum sound proof
  • Surface treatment: veneer, melamine
  • Coefficient: 30-60db
  • Width: 800-1230mm
  • Height 2000-4200mm
  • Color: multi-color design decorative sliding partition walls
  • Fireproof: Yes
  • Environment: E1 level

Acoustic Partition Walls Cases

Acoustic partition walls are made of high-quality anodized aluminum frame and environmentally friendly composite panels that move on ceiling tracks and do not require floor rails. The standard thickness of the panel is 65mm, 80mm and 100mm and the width is up to 1219mm. The maximum height is up to 17 meters high.

The acoustic partition walls consists of a series of interlocking panel and a quick set of foldable top and bottom seals. STC 32 to 53 is reached in the laboratory environment. Its excellent performance in sound insulation and the easy operation make it ideal for restaurants, schools, offices, religions, hospitals, shopping malls and many other indoor applications.

A wide range of finish options are available for acoustic partition walls: melamine faced MDF or particle board, fabric, carpet, leather, veneer, high pressure laminate, deck, acoustic board, white board. The panels can also supplied unfinished for site decoration.

Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish

Acoustic partition walls advantages

Use one wall to turn a large meeting room into two smaller ones.

Your office can be changed according to your needs - easily and quickly.

Within no time, you can have several separate rooms.

You do not need to build anything - you will get more space for significantly less money.

Visible aluminium profiles – anodised or powdercoated.

A wide range of panel finishes – laminated, veneered, covered with cloth or sheet metal, or even as rock imitation; attractive and very durable HPL film suitable for highly exposed areas.

Solid panels can be installed in combination with partially or fully glazed panels.

We also provide panels with a special acoustically absorptive surface.

Acoustic Operable Sliding Foldable Partition Wall Panels MDF Laminate Finish

Acoustic partition walls technicals

Series BG65 BG80 / BG85 BG100 & BG125
Panel suspension Top hung only Top hung only Top hung only
Track system Single or twin point Single or twin point Single or twin point
Panel thickness 65mm 80mm / 85mm 100mm
Panel height Up to 4000mm Up to 6000mm Up to 18000mm
Max height 4000mm 6000mm 18000mm
Panel width 600-1230mm 600-1230mm 600-1230mm
Frame construction Aluminum frame Aluminum frame Aluminum frame
Face material 9mm 9mm / 12mm 12mm
Fire safety Optional Class I or O Optional Class I or O Optional Class I or O
Vertical profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles Aluminum anodised with sealing profiles
Retractable seals Aluminum black with
double rubber seals		 Aluminum black with double rubber seals Aluminum black with double rubber seals
Operation of seals Manual, with supplied
operating handle		 Manual, with supplied operating handle Manual, with supplied operating handle
Locking Optional lock to pass doors Optional lock to pass doors Optional lock to pass doors
Pass doors Single open in panel or
double open in two panel		 Single open in panel or double open in two panel Single open in panel or double open in two panel
Sound insulation 32-38dB Rw 36-45dB Rw 42-55dB Rw
Weight Approx 22-35kg/sq M Approx 25-40kg/sq M Approx30-48kg/sq M
