Banquet Hall Aluminum Frame Movable Acoustic Folding Partition Walls Price
Details of Sound Proof Partitions
With the unique multi-layer panel system, our pattern 100 sound proof partition wall has excellent acoustic performance with a STC up to 40-50 dB.
Double PVC seals are mounted around the sound proof partitions to provide the highest level of acoustic integrity. More importantly, this fit can also achieve the desired acoustic integrity between two nearby rooms.
The acoustic structure includes multi-layer board at the top and bottom of the sound proof partitions and the glass wool inside. The acoustic performance is up to 40 STC, and the fabric wrapped acoustic panel and perforated MDF panel can be used to reduce echo. The vinyl at all edges help to prolong life time and seal the noise.
These sound proof partitions will be provided in an end-folded configuration to meet a variety of parking requirements and the first panel can be provided as a standard access door.
The sound proof partition has aluminum profiles, and panels are available for a variety of surface treatments including painted, polished veneer or various standard or high pressure laminate. Fire rated finish panel is also available.
Specifications of BUNGE Sound Proof Partitions System
Series | BG65 | BG85 | BG100 |
Panel suspension | Top hung only | Top hung only | Top hung only |
Panel thickness | 65mm | 85mm | 100mm |
Max height | 4000mm | 6000mm | 18000mm |
Panel width | 500-1200 mm | 500-1200 mm | 500-1200 mm |
Face material | 9mm | 9mm | 12 mm |
Pass doors | Single door or Double door | ||
Sound insulation | 28-38dB Rw | 28-42dB Rw | 32-50dB Rw |
Finish Material | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting, etc. (Customized) |
Features of BUNGE Sound Proof Partitions System
1.The sound proof partition materials are varied and varied, and the characteristics of the space can be selected according to the overall decoration style.
2.The outer frame of the sound proof partition is made of aluminum alloy, and its decorative surface is satisfied according to the customer's needs. For example, the veneer is made of non-combustible material and has strong fireproofing material. And the sound insulation effect of the sound proof partition is also very good.
3.The sound proof partition is highly utilized, its design is the integration of parts, which is to facilitate the better combination, so its combination is powerful, it can be reused, which reduces the cost of customers, can also achieve environmental protection. Energy saving and other functions.
4.The installation period of the sound proof partition can be short, and the pollution of the construction is small, so that the entire project can be quickly improved. Efficiently meet the needs of customers.
5.The choice of sound proof partitions can be varied, according to the needs of the hotel, use different kinds of sound proof partitions, choose a suitable one for the hotel style, will bring more aura to the hotel.
6.The biggest feature of the sound proof partition is that it can be moved and can be reused. Its material will not bring waste to the environment. Therefore, the movable partition material is a green material. For example, many company addresses will be continuously relocated. Then the company needs to consider the reusability of the company's installed sound proof partition, which is more convenient for the user's service life, so it is a relatively cheap and cost-effective decoration.
7.About the sound proof partitions,there are many colors to choose, a variety of material components can be used in conjunction with each other, which can reduce material waste. It is efficient, stylish, elegant, concise, generous, beautiful and exquisite.
Common Applications of Sound Proof Partitions System
Sound proof partition is usually used where indoor space needs to be fully utilized. Hotels, convention centers, educational institutions, offices, training areas, etc. can all benefit from the flexibility of sound proof partitions system.
