Specifications
Brand Name :
BANGE
Model Number :
85 mm folding partition walls
Certification :
ISO9001
Place of Origin :
Guangdong
MOQ :
10 square meters
Price :
US Dollars 80 - 138 per square meters
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000 square meters per month
Delivery Time :
15-20 days
Packaging Details :
Carton package, MDF batten on four section sides , foam board on both front face.
Product name :
Folding partition walls
Feature :
Sound insulation
Colors :
Accept customized
Application :
Hotel,banquet hall
Material :
MDF+Melamine
Style :
Sliding,movable
Description

Banquet Hall Decorative Types of Folding Conference Room Partition Walls

Description of Folding Partition Walls

BUNGE folding partition walls are able to supply you with acoustic partitions that will look good and last for years to come, with endless possibilities of surface finishes, from standard laminate, real wood veneers, painted finishes, black board, or ready to onsite decorate by customer i.e. painting / wallpapering etc. Conference room partitions are top hung so have no floor tracks, and are more forgiving on uneven floors, with sound reduction available up to 52db.

Options include full height or inset pass doors, and glazing panels, easy to operate each panel,is manually positioned and secured into place with a winding handle to operate the mechanical seals top and bottom.

All of our folding partition walls are of the highest quality, very robust and easy to manoeuvre, and manufactured in the China, the conference room partitions panels can be stacked either in-line (single point suspension) or off-line at either end of the top track (two point suspension), with different track variations possible to suit your needs.

Folding partition walls allow you to segregate your space for maximum potential, and are the perfect flexible space-saving solution for areas that require a partition with a higher specification.

Muti - Function Heat Insulation Sliding Folding Partition Walls Floor To Ceiling

Features of BUNGE Folding Partition Walls System

1.Folding partition walls can separate the space speedy and conveniently.

2.Muti-function: sound insulation,heat insulation,fireproof function.

3.Top hung system without the need for a floor track.

4.The folding partition walls are made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.

5.Around the folding partition walls panel, there is sound insulation rubber, it can help to insulate the sound entering.

Muti - Function Heat Insulation Sliding Folding Partition Walls Floor To Ceiling

Technicals of Sound Proof Partitions

Description of the whole system
Item Sound proof partitions
Partition Height From 2 meters to 15 meters.
Sound Transmission Class(STC) From 32db to 53db.
Optional Mode Connected & seperated, sealed & non sealed
Description of accessories
Series Type 65, Type 80, Type 100
Track System Clear anodized 6063-T6 aluminum track;Imported dupont POM material roller,bearing capacity from 225kg to 250kg.
Junction "T"junction, "L" juntion, cross/ "X" juntion.
Finishes 15mm fabric acoustic panel, Wood veneer, Laminate, Melamine, PU etc.

Installation of Folding Partition Walls

1. After the folding partition walls rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the ceiling shape, the ground shape, whether there is a skirt line on the wall, etc., timely communicate with the on-site woodworker, and then release the line to determine the track installation. position;

2. After the horizontal line is placed, the construction side will determine the layout direction of the air-conditioning duct fire-fighting pipe, and it is convenient to determine the steel structure installation form, whether it is a straight pull or a diagonal support or a U-slot fix. These are responsible installation teams. Do the preparation before the construction, otherwise work and do things, when the impact on the site construction layout, but also to rework, seriously affect the construction progress, will also bring unnecessary trouble to Party A;

3. After the folding partition walls track is installed, the track level will be self-checked again, and finally the steel structure will be rust-proofed, and then Party A will be notified and the position of the track movable port will be clearly stated. When the ceiling is clearly indicated, it cannot be fixed with the track. Otherwise,the conference room partitions panel will likely damage the integrity of the ceiling.

Muti - Function Heat Insulation Sliding Folding Partition Walls Floor To Ceiling
