Laminate Sliding Doors Partition Walls , Sliding Glass Doors
Laminate Sliding Doors Partition Walls , Sliding Glass Doors
Specifications
Brand Name :
BUNGE
Model Number :
Type65
Place of Origin :
China
MOQ :
10 Square Meters
Price :
US $ 100 - 300 / Square Meter
Payment Terms :
T/T
Supply Ability :
5,000 Square Meters per Month
Delivery Time :
10 working days after received your payment
Packaging Details :
Carton package , MDF batten on four section sides , foam board on both front face
Width :
800 - 1230mm
Thickness :
65mm
Application :
hotel , hall .meeting room and so on
Material :
melamin , fabric , veneer , laminate
Open Style :
Sliding
Position :
Commercial
Description

Sliding Partition Walls , Top Hung Movable Partition , Folding Sliding Partition

Specifications:

Technical Parameter for Partition Panel

Panel Width

500 - 1230mm

Panel height

2000 - 4000mm

Sound proof

32 - 36db

Operation

Manual

Frame

Aluminum

Vertical profile

Anodised aluminum profiles with integrated magnetic strip and sealing edges on the inside

Finish options

Fabri c, veneer , HPL melamine , vinyl , carpet , customers own material , Bare finish

Base options

Plywood , Gypsum , steel , MDF

Max width

Unlimited

Panel weight

25 - 40 kg / sq

Pass door selection

door

Single or double door

Seals

Top

Manual

bottom

Manual

Description :

The operable wall panel construction and finish materials shall consist of Class A rated materials in accordance with BUNGE Standards .

Operation :

Partitions shall be top supported , manually operated panels stacked in an area nominated in the plans. When closed , the operable wall shall provide a complete sound retardant barrier . No floor track shall be used .

Track :

The tracks are made from extruded 6063 – T6 anodized aluminum . The track housing shall utilize grooves and interlocking steel pins for positive alignment of adjacent track sections , and shall be reinforced overhead by drop rod brackets . Aluminum track housing shall include an integral nut slot to accept a hardened square nut for attaching each drop rod bracket to the top of the track .

Stacking :

The panels will be stacked as per the agreed method and in accordance with the architetural plan. Centre stacking arrangement will be utilized for the subject project.

Applications :

Our products (Movable Partitions) are widely used in the hotel banquet halls , meeting rooms , exhibition halls , conference rooms , International Convention Centers , KTVs , upscale restaurants , office buildings , schools , hospitals and others .

Laminate Sliding Doors Partition Walls , Sliding Glass Doors

Laminate Sliding Doors Partition Walls , Sliding Glass Doors
