Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
Specifications
Brand Name :
BUNGE
Model Number :
65 series
Place of Origin :
China (mainland)
MOQ :
No MOQ
Price :
USD 80-90 Square meters
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
5000 Square meters per month
Delivery Time :
15 days
Packaging Details :
Partition board paper packaging, and finally packed in wooden carton
Product name :
Folding partitions wall
Material :
aluminum frame
Color :
Customized
Function :
Divide Space
Style :
Morden
Thickness :
65 mm
Height :
Max 4000 mm
Warranty :
3-5years
Usage :
Exhibition Booth
Finish :
melamine
Description

Demountable Partition Walls Acoustic Partitions Exhibition Booth Folding partitions wall

1: Moving wall surface without track, just install track on the ceiling (or floor).

2: After the moving wall is stable, it is reliable and not easy to swing, stable and safe

3: Mobile wall sound insulation effect is good, the maximum sound insulation coefficient can reach 55db

4: Excellent insulation performance of mobile wall, according to different seating rate, the large space is divided into small space, in order to reduce the power consumption of air conditioning

5: Mobile wall beautiful and generous, arbitrary surface decoration, and indoor unified decorative effect

Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height

Series BG 65 BG 85 BG100
Panel supension Top hung only Top hung only Top hung only
Panel thickness 65 mm 85 mm 100 mm
Max height 400 mm 600 mm 800 mm
Panel width 600-1230 mm 600-1230 mm 600-1230 mm
Face material 9 mm 9 mm 9 mm
Pass doors Single Door or Double Door
Sound insulation 20 – 32 db 28 – 36 db 32 – 50 db
Finish Material Plywood / MDF /Laminate / Melamine / Gypsum
Board / Fabric / Insulation / Fireproof /Wall Paper /Vinyl /Painting /etc,(Customized)

Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height

The production process of partition wallboard

1: The cut aluminum, double round pipe, double transmission rod and other hardware parts assembled together, forming a basic frame of the door, the frame is the foundation, the most important process of the entire partition wall board

2: Soundproof cotton is filled in the door panel, so that the partition wallboard has a more three-dimensional feeling, the sound of knocking the door panel is smaller, while playing an effective sound insulation effect

3: Each wallboard shall be packaged on the second floor, with bubble film inside, effectively protecting the partition wallboard and outsourcing paper to prevent it from being scraped. From the production to the packaging of more than 100 to the working procedure, each layer shall be checked to make every detail perfect

Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height

Installation site of partition wall

1: Installation track

Track is the base, is the priority among priorities of all links, through percussion drilling expansion screws, welding Angle iron and other steel materials fixed up.

2: Insert the door panel

The moving door panels are suspended in the rails without any support on the ground.

3: Installation and debugging

Free and flexible, move the door panels according to whatever you need to change the layout

4: Close against the wall

Convenient collection, save space

Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height

Partitions wall Hardware accessories

Frame, transmission rod, single wheel seat, multi-layer plate, handle, sound insulation cotton, screw, track, Angle code, sealing strip, aluminum, telescopic mechanism, lifting wheel, double wheel seat

Exhibition Booth Acoustic Demountable Partition Walls Max 4000mm Height
