Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
Specifications
Brand Name :
EBUNGE
Model Number :
85 mm folding partition panels
Certification :
ISO9001
Place of Origin :
Guangzhou, China
MOQ :
No MOQ, small quantity welcomed
Price :
US $78-95 per square meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000 square meters per month
Delivery Time :
12-20 days
Packaging Details :
Paper carton, outside with wooden boxes
Product name :
Folding partition panels
Thickness :
85 mm
Application :
Classroom folding partition
Rock wool infill :
55 kg/m3
Surface :
Laminate
Access door :
Single or double
Description

Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines

Folding partition panels structure

The folding partition panel is made up of four main parts, they are:

The main body. This part is usually the combination of high quality of glued wood and aluminum alloy material. The standard size can be (800-1200)*3500*65mm/(800-1200)*4500*80mm/(800-1200)*4500*100mm.

The pulley. It is the important part of folding partition panels which promising the partition moves freely.

The folding partition panels track. This part is made for providing the railway for the movement of the pulley, without which, the free movement of this product can’t be realized.

The operating crank handle. With it, you can adjust the height as you love.

Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines

Technical information

Model BG-65 series BG-85 series BG-100 series BG-high series
Suspension system Aluminum hanging Aluminum hanging Aluminum hanging Steel hanging
Basic thickness 65mm 85mm 100mm 100mm
Total thickness 65/75/85/95mm 85/90/100/110mm 100/120/130mm 100/120/130mm
Max height Up to 3800mm Up to 4500mm Up to 6500mm Up to 12000mm
Width 600-1230mm 600-1230mm 800-1230mm 800-1230mm
Floor/ceiling sealing strength Telescopic aluminum tube with rubber strip
Side walls sealing strength Double seal tape
Sound insulation level 26dB-30dB 28dB-34dB 32-40dB 32-40dB
Panel structure Aluminum frame with wooden keel Aluminum frame with steel keel
Panel density 22-28kg/sqm. 24-32kg/sqm. 32-50kg/sqm. /
Surface material Melamine laminate/fabric/PU leather/wallpaper/veneer/customized

Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines

Different finishes of folding partition panel

  • ❶ Wooden (MDF, Plywood bare raw finish) (Melamine, Veneer)

  • ❷ Fabric (fabric with mdf board hard covers) (fabric with sponge soft covers)

  • ❸ Leather (leather with mdf hard covers) (leather with sponge soft covers)

  • ❹ Wallpaper, Vinyl, Fireproof board

  • ❺ Acoustic panels

  • ❻ Tempered glass, mirror etc.

  • Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines

Packaging for the track system

Normally if the client only buy the folding partition panels accessories, we always pack the tracks by a paper carton, and the accessories will be packed by some wooden boxes.

Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines Classroom Acoustic Movable Partition Sound Proofing Folding Partition Wall Panels Philippines
