MDF top gypsum board office portable movable partition walls fabric partition folding doors for hotel

Description:

Movable partition wall can separate the space speedy and conveniently.There is top hung system without the need for a floor track.Conference room soundproof wall partition is made from high density aluminum frame, special made rubber, excellent sound insulation cotton and finish surface, etc.

Around the panel, there is sound insulation rubber, it can help to insulate the sound entering.Soundproof movable partition wall is hanging on the aluminum track, assembled with muti direction wheels.

Technical parameters:

Movable partition wall include the track, hanging wheel, sealing strip, frame, finish, sound insulation material, telescopic mechanism, sealing strip and other parts.

1. Track: the material is made of 6063-t5 anodized aluminum, which is used for hanging the partition.

2. Double roller: the roller is made of POM, the screw is made of no. 45 tempered steel, and the hanging partition can be rotated at any Angle on the horizontal plane, and can pass through the intersection point of L,T and X of the track along the pulley.

3. Roller seat: the material is A3 steel, which connects the roller with the partition.

4. Top and bottom seal aluminum: the material is anodic aluminum oxide.Sealing the gap between the partiton to ceiling and partition to gorund. It's soundproof and can fixed the partition.

5. Sealing tape: material is PVC, surface color is black.It can reduce the sound and light.It acts as a buffer when the movable partition touched the wall.

6. Base board: medium density fiberboard,also called MDF board.

7. Sound-proof cotton: PAR sound-absorbing glass fiber. Fireproof performance, thermal resistance and noise reduction coefficient are all in line with relevant standards.

8. Aluminum frame: All the frame is made of aluminum.

9. Telescopic mechanism: it is made of standard A3 steel and spring steel, operated by pressure spring, which can automatically adjust the gap between the screen and the ground.

10. Handle: made of standard A3 steel, it is used for operating up and down telescopic mechanism.

11. Finish structure: Movable partition finish can be glass, melamine, fireproof board, fabric, leather,gypsum board and other decorative materials.

12. Light steel keel:Medium density double-sided plastic board partition and polyurethane foam insulation composite board partition, instead of the traditional brick wall paint, you can see with the progress of science and technology in our country, bring people's lives great changes.

Installation:

Movable partition wall is composed of many single panels.Each panel is equipped with single or two hanging rollers.It depends on the horizontal hanging roller to make the partition panel hanging along the track.The vertical contact points of each single panel are connected by concave and convex positions.The seal rubbers are embedded and panel top and bottom parts are equipped with a retractable mechanism.

When closing, the partition can be hidden in a dedicated storage cabinet, which does not affect the overall appearance.
