Weight ≤10000g Electro Optical Pod Eagle-Eye10000 Heading NX360°
Weight ≤10000g Electro Optical Pod Eagle-Eye10000 Heading NX360°
Weight ≤10000g Electro Optical Pod Eagle-Eye10000 Heading NX360°
Weight ≤10000g Electro Optical Pod Eagle-Eye10000 Heading NX360°
Specifications
Brand Name :
Forward
Model Number :
Eagle-eye10000 Electro Optical Pod
Place of Origin :
China
MOQ :
1 pcs
Payment Terms :
L/C, T/T
Supply Ability :
500 pcs/years
Packaging Details :
boxes
Price :
Negotiable
Type :
gyrostabilization
Weight :
≤10000g
Heading :
NX360°
Pitch :
+20°～-110°
Angular Position Accuracy :
≤ 35μrad（RMS）
Dimensions :
φ240mm×362.1mm
Operating Temperature :
-40℃～+55℃
Laser Ranging :
50~6000m
Description

Electro Optical Pod Eagle-eye10000 Weight ≤10000g Heading NX360°

Descriptions of Electro Optical Pod:

Eagle-eye10000 electro optical is equipped with visible light TV, cooling infrared thermal imager and laser range finder. It has the characteristics of good stability, good observation effect, general purpose and high reliability. It can be used to perform tasks such as target search, capture, identification and tracking, and is suitable for various aircraft and vehicle platforms.

Features of Electro Optical Pod:

  • High-precision boresight stabilization function;
  • Has visible light and infrared reconnaissance functions;
  • With laser ranging function;
  • Visible light TV has functions such as optical continuous zoom, automatic focus and image enhancement;
  • The thermal imager has the functions of optical continuous zoom, automatic focus, polarity conversion, non-uniformity correction and image enhancement;
  • With manual mode, lock mode, scan mode and automatic tracking modes;
  • Multi-target detection and prompt function;
  • It has the function of completing target positioning and geographic guidance according to the carrier information;
  • With high-definition image recording, ground data transfer function.

Specifications of Electro Optical Pod:

Specification

Type: Gyro Stabilized

Weight: ≤10kg

Dimensions: ≤φ240mm×362.1mm

 Infrared Thermal Imaging

Detector Refrigerated medium wave HgCdTe (mercury cadmium telluride)

Resolution 640×512

Working band 3μm ~ 5μm

Field of view 1.84°×1.48°～ 35°×28°

Detection distance: ≥8km,

Recognition distance: ≥5km
Features

Two axes (pitch axis: +20°~-110°;

Heading axis: NX360°;

Stable accuracy: ≤ 35μrad(RMS)

Angle measurement accuracy ≤1mrad

 Visible Light Imaging

Resolution 1920×1080

Working band 0.4µm～0.7µm

FOV 2°×1.12°～52.5°× 29.4°

Detection distance: ≥10km

Recognition distance: ≥7km
Laser Ranging


Working wavelength 1.54μm

Ranging range 50m～6000m

Ranging accuracy ≤2m
Tracking module

Tracking accuracy ≤0.6mrad (RMS)

Maximum search angular velocity ≥60°/s

Maximum tracking angular velocity ≥10°/s

 External interface

Control interface :

2 way RS422 serial port

Video output :

1 channel network digital video output

1 synchronous 422 video output

1 channel HD-SDI video output
Power supply

Voltage: 28 VDC,

Power consumption: ≤80W (average),

≤200W (peak)

 Environmental conditions

Working temperature -40℃～+60℃

Storage temperature - 50℃～+70℃
