Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch
Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch
Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch
Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch
Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch
Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch
Specifications
Brand Name :
ANYO
Model Number :
322CQS
Certification :
IEC60998 UL1059 standards
Place of Origin :
CHINA
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30000pcs per day
Delivery Time :
8-10 work days
Packaging Details :
customized carton
Other name :
Fuse terminal block
Housing :
PA66(UL94V-0)
Clamp :
Brass
Pitch :
7.62mm
Position :
02P~37P/19P/13P
Temperature :
-30℃ ~ 85℃
Description

Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch

Feature:


Pitch: 7.62 mm (single pitch or double pitch)
Nominal current: 16A per contact
Nominal voltage: 320 Volt
Material Contacts: FePO2
Temperature Rating: -30℃ to 85℃

Material:

Conductive clamp: Brass with tin plating

Housing: PA66(UL94V-0)

Electrical and Mechanical:

Test standard IEC60998-2-1/UL1059
Pitch 7.62
Number of poles 02P~37P/19P/13P
Frequency voltage AC 2500V per minute
Rated surge voltage 4000V

Dimension:(mm)

Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch

Vertical Faston Connector CQS For 4-pole PCB With 7.62mm Pitch
