Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor
Specifications
Brand Name :
ANYO
Model Number :
PCT-212
Place of Origin :
CHINA
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30000pcs per day
Delivery Time :
8-10 work days
Packaging Details :
customized carton
Other name :
Wire connector
Application :
Power
Strip length :
9~10mm
Wire range :
0.08~4.0mm2
Rated voltage :
400V
Rated current :
32A
Description

Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor

Feature:

• More safety and fast

• Use insulating tape

• Easy open and close

• Nylon material

• High presure with copper clips

• Easy for test and repair

Electrical and Mechanical:

Rated voltage 400V
Nominal current 32A
Rated surge voltage 4KV
Solid sizes 0.08~2.5mm2/28~12AWG
Fine-standard wires 0.08~4mm2/28~12AWG
Strip length 9~10mm/0.35~0.39"
Temperature range -40℃ ~ 105℃

Dimension:(mm)

Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor

Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor

Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor

Applicable cable:

Spring Lever Reusable Wire Connector Adapter 32A 2 Way Conductor

How to use:

• Strip the wire insulation jacket 9~10mm

• Pull the operating handle to open the inlet hole and insert the wire

• Then return the operating handle to its original position and the wiring operation is completed
