Product Overview

The B82721K2701N020 is a high-performance common mode choke, designed for industrial and consumer electronics applications. It effectively suppresses electromagnetic interference (EMI), ensuring the smooth operation of devices and the stability of data transmission.

Key Features

• Excellent Electromagnetic Interference Suppression: This product uses high-quality materials and advanced design to provide outstanding common-mode inductance across a wide frequency range, significantly reducing common-mode noise.
• High Saturation Current: Capable of handling high saturation currents, making it suitable for applications requiring large currents.
• High Reliability: Rigorously tested and verified to maintain stable performance even in harsh working environments.
• Compact Size: Its compact design allows for easy installation on space-constrained circuit boards.

Technical Specifications

• Inductance: 27 mH
• Rated Current: 2 A
• Saturation Current: 2.7 A
• Direct Current Resistance (DCR): 0.02 Ω
• Operating Temperature Range: -40°C to +125°C

Application Fields

• Switching Power Supplies: Used to suppress high-frequency noise, ensuring stable output in switching power supplies.
• Frequency Converters: Effectively reduces electromagnetic interference, improving system reliability and efficiency.
• Home Appliances: Applied in household appliances such as washing machines and refrigerators to reduce electromagnetic radiation and protect sensitive electronic components.
• Industrial Equipment: Widely used in industrial automation equipment to enhance interference resistance.

Installation and Usage

The B82721K2701N020 is easy to install and suitable for standard Printed Circuit Boards (PCBs). During use, ensure proper connections to avoid overcurrent and overheating.

Reasons to Buy

Choosing the B82721K2701N020 means opting for a superior-performing common mode choke along with reliable quality assurance and excellent technical support. It will provide long-lasting and stable electromagnetic interference suppression, ensuring your electronic devices perform optimally in any environment.

Purchase the B82721K2701N020 now and take your electronic device performance to the next level!
