36 Connector Fiber Optic Polishing Equipment Fixture Jigs
36 Connector Fiber Optic Polishing Equipment Fixture Jigs
Specifications
Brand Name :
KCO, Kocent Optec Limited
Model Number :
KCO-4JIG-FCA-36
Certification :
RoHS, ISO
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
200,000 pcs/ month
Delivery Time :
2~5 days after get payment
Packaging Details :
paper bag, carton box
P/N :
KCO-4JIG-FCU-36
Grade :
0.3dB, 3D
Polishing scope :
SC/UPC connector
Disk Size :
179mm
Connector :
36 connector
Machine :
Corner pressure polishing machine
Description

FC/UPC Fiber Optic Connector Polishing Jigs 36 Ports 3D Pass For Four Corners Polishing Machine

Description:

- The polishing jigs (or also be called polishing fixture) is using to fix the fiber optic connector when polishing.

- It is one of most importance part in the fiber optic patch cord production line.

- A good polishing jigs can help make to high quality that can pass 3D of fiber optic patch cord / pigtail.

- This polishing jigs is designed for corner pressure fiber optic polishing machine only.

- It has 36 FC/APC adapter on the jigs, maximum can polish 36 connectors each time, increase grinding efficiency
- It is suitable for FC/APC connector polishing style.
- Come with 36 positions for connector head.
- Polishing 36 connector a time.

- FC/APC poloshing jig is available in 24 ports, 32 ports, and maximum 36 ports.

Feature:

- The interference rate of 2. is over 90%.

- High quality steel construction, high precision.

- Each grinding disc can be fitted with a plurality of grinding heads, and the production efficiency is high.
- Adapters interchangeable to extend the service life of the grinding disk.
- Three kinds of grinding heads, SC/PC, FC/PC, ST/PC, interchangeable.

- The utility model saves the number of the grinding disk and saves the production cost.
- Grinding can be integrated grinding disk, also suitable for rework.
- The use of independent afterburner way to eliminate the grinding head of different length of exposure on the impact of grinding.

- According to customer requirements design, APC, MPO, E2000, MTP, MPX and so on.

36 Connector Fiber Optic Polishing Equipment Fixture Jigs

36 Connector Fiber Optic Polishing Equipment Fixture Jigs

36 Connector Fiber Optic Polishing Equipment Fixture Jigs

Specification

Product Size
174mm*174mm*5.1mm
Wet weight
About 1.2kg
Application
Fixed FC / APC Fiber Connector Polished
Suitable Fiber Connector Polisher
Four-corner pressure optical fiber connector polishing machine
Material
Hardened stainless steel2316

Applications:

Product Type Application
D

· Lapping for Fiber optic connector, fiber array, glass pig tail(angel removal, rough grinding, medium polishing, fine finishing)

·Polishing for magnetic heads and hard disks

·Lapping and polishing for optical glasses, optical crystal , LED

·Lapping and polishing for Semiconductor wafer (gallium arsenide, indium phosphide etc.)

·Edge polishing for silicon wafer
SC

·Epoxy and glass removal

·Lapping and polishing for plastic ferrules

·Fine finishing and polishing for magnetic heads
AO

·Polishing for fiber optical connectors

·Polishing for silicon wafer used in Solar cells

·Polishing for hard disks

·Polishing for ITO

·Lapping and polishing for optical crystal
CO

·The final polishing for fiber optical connectors

·Polishing for optical devices
SO ·The final super-precise polishing of optical fiber connector

Specifications:

Type D(Diamond) SC (Silicon Carbide) AO(Aluminum Oxide) CO(Cerium Oxide) SO(Silicon Oxide)
Grit Size/um 30 Green Light Green Green 　 　
20 　 　 　 White 　 　
16 　 　 　 White 　 　
15 Yellow-Green Tawny Light Green Brown 　 　
12 　 　 　 Yellow 　 　
9 Blue Orange Gray-green Blue 　 　
6 Yellow 　 　 　 　
5 　 　 Gray-green White 　 　
3 Pink Tan Pink & White 　 　
2 　 　 Gray-green Bright Green 　 　
1 off-white Lavender Gray-green Blue 　 　
0.5 off-white Brown-yellow 　 White White 　
0.3 　 　 　 White Dark Red 　
0.2 Grey 　 　 　 　
0.1 Light Brown 　 White 　 　
0.02 　 　 　 　 　 Transparent
0.01 　 　 　 　 　 Transparent
Recommended Polishing Medium Water/Oil Water/Oil Water/Oil SOQ-12D Water
Standard Size

Disk:Φ70mm,

Φ110mm,

Φ127mm(5inch),

Φ203mm(8inch)

Sheet:

114mm*114mm,

152mm*152mm(6inch),

228*228mm(9inch)
Note: Other film sizes are available upon request.

Fiber Optic Patch Cord Production Process:

36 Connector Fiber Optic Polishing Equipment Fixture Jigs

OEM/ODM Service:
- If you want to show your own brand LOGO on the goods such as cable, package bag, label or any where. Our OEM and ODM service is always ready to do it. Please contact with our sales team to get best support.

Packing:
- According to Stardard Export Packing.
- Carton box, wooden box, wooden pallet.

Shipping:
- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- By sea
- Standard export sea port: Shenzhen, Hongkong, Ningbo
- Standard export airport: Shenzhen, Hongkong, Hangzhou, Shanghai

Product tags
