Multimode OM3 Fiber Optical Coupler PLC Splitter 1*2 1*4 1*8 SC LC FC ST Connector
Multimode OM3 Fiber Optical Coupler PLC Splitter 1*2 1*4 1*8 SC LC FC ST Connector
Multimode OM3 Fiber Optical Coupler PLC Splitter 1*2 1*4 1*8 SC LC FC ST Connector
Multimode OM3 Fiber Optical Coupler PLC Splitter 1*2 1*4 1*8 SC LC FC ST Connector
Multimode OM3 Fiber Optical Coupler PLC Splitter 1*2 1*4 1*8 SC LC FC ST Connector
Multimode OM3 Fiber Optical Coupler PLC Splitter 1*2 1*4 1*8 SC LC FC ST Connector
Specifications
Brand Name :
KCO, Kocent Optec Limited
Model Number :
KCO-ABS-1x8-OM3-3.0-1.0M-LC
Certification :
ISO9001, RoHS
Place of Origin :
Guangdong, China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
20,000 set/ month
Delivery Time :
2~5 days
Packaging Details :
Carton box, wooden pallet
Package type :
ABS box modular
Length :
1.0m
Splitter type :
1*8 1x8
Connector :
LC
Cable :
0.9mm/ 2.0mm/ 3.0mm
P/N :
KCO-ABS-1x8-OM3-3.0-1.0M-LC
Description

Multi Mode Plc Optical Coupler 1*2 1*4 1*8 SC LC FC ST Connector

Multi-mode Optical Fiber MM Splitter Coupler 1*2 1*4 1*8 1*16 1*32 SC LC FC ST Connector​

Descriptions:
- Multimode Fiber Optic Coupler allows bi-directional coupling and can be used to either split or combine signals. It uses 50/125 or 62.5/125μm fiber, with low insertion loss and a 850nm operating wavelength.
- This 1x8 coupler features a fully ruggedized black plastic housing with 1 meter long, 3 mm PVC covered pigtails with FC/PC connectors.

- The MM graded index couplers offer low insertion loss and excellent environmental and mechanical stability.

- The multimode couplers are available in 50/125um and 62.5/125um fiber types and operate at 850nm or 1310nm wavelength range.

- Multimode Couplers are available with 3mm cable jacket, 900µm loose tube jacket or 250µm bare fiber.

- It is a passive optical device with many input and output terminals, especially applicable to PON (EPON, GPON, BPON, FTTX, etc.) to connect the MDF (main distribution frame) and the terminal equipment and to branch the optical signal.

- Fiber optic splitter provides a low cost light distribution solution with high stability and reliability.

Introduction:

- Kocent Optec Limited supply full series of fiber optic PLC Splitter such as: Mini Tube Type, ABS Box Modular Type, LGX box type, Rackmount type, Wall mount type, ....

- Our product catalog:

+ Fiber optic splitter

+ Fiber optic patch cable

+ Fiber optic cable

+ Fiber optic terminal box

+ Fiber optic splice closure box

+ Fiber optic accessories

Features:

- Low Insertion Loss.
- Low PDL.
- High Return Loss.
- Uniform Power Splitting.
- Wide Operating Wavelength.
- Wide Operating Temperature.
- Good Environmental Stability.
- High consistency

Applications:
- FTTX Deployment

- FTTH Network
- CATV System

- Optical Signal Distribution
- Passive Optical Network(PON)

- Fiber Optic systems
- Measuring System

- Laser System
- DWDM and CWDM System

- Fiber Optic CATV
- Fiber to home(FTTH)
- Passive Optical Networks (PON)
- Local Areal Networks(LAN)
- Fiber communication systems.

Specifications:

Fiber length 1m or custom length
Connector Type Custom specified
Optical Fiber Type Corning SMF-28e fiber, G657A1 or as customized
Directivity (dB) Min * 55
Return Loss (dB) Min * 55 (50)
Power Handling (mW) 300
Operating Wavelength (nm) 1260 ~ 1650
Operating Temperature(°C) -40~ +85
Storage Temperature(°C) -40 ~ +85
Port Configuration 1x2 1x4 1x8 1x16 1x32 1x64
Insertion Loss(dB) Typical 3.6 7.1 10.2 13.5 16.5 20.5
Insertion Loss (dB) Max 4.0 7.3 10.5 13.7 16.9 21.0
Loss Uniformity (dB) 0.6 0.6 0.8 1.2 1.5 2
PDL(dB) 0.2 0.2 0.2 0.25 0.3 0.35
Wavelength Dependent Loss(dB) 0.3 0.3 0.3 0.5 0.5 0.5
Temp. Dependent Loss (-40~85 ) (dB) 0.4 0.4 0.4 0.5 0.5 0.5
Port Configuration 2X2 2X4 2X8 2X16 2X32 2X64
Insertion Loss(dB) Typical 3.8 7.4 10.8 14.2 17 21
Insertion Loss (dB) Max 4.2 7.8 11.2 14.6 17.5 21.5
Loss Uniformity (dB) 1 1.4 1.5 2 2.5 2.5
PDL (dB) 0.2 0.2 0.4 0.4 0.4 0.5
Wavelength Dependent Loss(dB) 0.8 0.8 0.8 0.8 0.8 1
Temp. Dependent Loss(-40~+85°C) 0.5 0.5 0.5 0.8 0.8 1

Product photos:

Our PLC Splitter Family:

OEM/ODM Service:
- If you want to show your own brand LOGO on the goods such as cable, package bag, label or any where. Our OEM and ODM service is always ready to do it. Please contact with our sales team to get best support.

Packing:
- According to Stardard Export Packing.
- Carton box, wooden box, wooden pallet.

Shipping:
- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- By sea
- Standard export sea port: Shenzhen, Hongkong, Ningbo
- Standard export airport: Shenzhen, Hongkong, Hangzhou, Shanghai
