R2000 Sensor Rfid Desktop Reader , Long Distance Rfid Reader Handheld With 1d / 2d Barcode
R2000 Sensor Rfid Desktop Reader , Long Distance Rfid Reader Handheld With 1d / 2d Barcode
Specifications
Brand Name :
SUNSHINE
Model Number :
P6300
Certification :
CE,ROSH
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, Western Union
Packaging Details :
Carton
Operating System :
Android 4.4 OS
RAM :
RAM: 2G/FLASH: 16G
Extended Storage :
Micro SD ,Maximum 32G
GPS :
Support GPS ,DBS ,GLONASS and professional GPS,Ublox;GPS and Beidou(alternative)
Far infrared meter reading :
woring frequency 37.9K
Identification distance :
not more than 6 m
Description

R2000 Sensor Long Distance Rfid Desktop Reader With 1d / 2d Barcode , 1280x800 Touch Screen

FEATURES

  • Advanced system: Android 4.4 operating system; quad core 1.2 GHz CPU; RAM 2G Three-proof design: IP67 three protection grade,
  • drop resistance from 1.2m Visible under strong light;
  • 7 inch LCD screen, 1280x800 IPS capacitive touch screen
  • Powerful function: multi function information acquisition configuration (1D/2D bar code scanning, LF/HF/UHF RFID reader, fingerprint identification) Multi communication modes:
  • support 4G, WIFI, Bluetooth and many wireless communication modes
  • Strong battery life: more than 600 hours of continuous standby

Application scenarios

  • Exhibition: Access control, data acquisition solution, RFID wrist strap technology solutions in the exhibition center,
  • Manufacture: garment manufacturer’s operational sequence solution
  • Interlock: running multiple shop’s management solution
  • Express: express and logistics industry’s mobile application
  • Transportation: jeeves,smart parking’s charging solution
  • Medicine: the application of the electronic supervision of drug
  • Highroad: road traffic inspection management solution
  • Asset: Mobile assets inventory management system, routing inspection management system.
  • Traceability: products/goods traceability management system.
  • Anti-fake: cigarettes and wine, valuables’ anti-fake application
  • Sales: the retail inventory, promotion, cargo inventory management
  • Agriculture: smart agriculture and forestry management solution, Temperature and humidity monitoring system.
  • Operator: the base station inspection, network optimization


SPECIFICATIONS

General Specifications
Operating System Android 4.4 OS
CPU MSM8916,A53,4core CPU ,1.2GHz
RAM RAM: 2G/FLASH: 16G
Extended Storage Micro SD ,Maximum 32G
USB port 5 pin MicroUSB, support OTG (U-disk/Mouse/keyboard/USBEthernet cable)
OTG Support,through OTG can meet 100M network port , network card setup,PPPoE dial-up,web browsing ,Support OTG extend RS232 serial port
External port Charge port ,headphone port
Protection Grade
Industrial Protection Grade IP67
Drop Grade Drop resistance from 1.2m
Wireless Communication
Bluetooth Support 4.0
GPS Support GPS ,DBS ,GLONASS and professional GPS,Ublox;GPS and Beidou(alternative)
WIFI Support IEEE802.11b/g/n
4G

FDD/WCDMA/GSM
LTE_FDD B1/B3/B7 LTE_TDD B41/B40
WCDMA B1/B2/B5
GSM 900/1800/1900
Data Acquisition(Optional)
Fingerprint Identification Support fingerprint data acquisition,fingerprint resolution 150x200
Far infrared meter reading woring frequency 37.9K
RFID
LF RFID 134KHZ LF RFID or 124KHZ LF RFID
NFC(HF) RFID

Working frequency : 13.56 MHZ
Profile: Support ISO/IEC 15693,ISO/IEC 14443A profile
Support Cards :SR176,SRIX4K(TYPE-B),I-Code2,TI RFID label-it
HF1,EM4034 ,Mifare Classic ETC
Identification distance :not more than 5cm
UHF RFID

Working frequency : 840-960MHZ
Support agreement :EPC C1 GEN2/ISO 18000-6C
Output power : 10dBm-30dBm
Identification distance : not more than 6 m
Physical Parmeters
Display Screen 7 inch LCD screen ,1280x800 IPS screen ,capacitive touch screen
Keyboard Android menu ,Homepage ,Returm,Volume,Barcode,ON/OFF ,Reset
Camera 2 million pixels front camera ,8 million pixels rear camera with automatic focus and lighting function
Headset 3.5mm audio interface,has mike and telephone receiver
LED indicatoe light Support (ordinary ficker,Call fast flicker ,missed calls ) three status bar
Flashlight Function Support ,can be used for emergency lighting
Googleplay store Support
Gravity sensor Support
Compass Support
Vibrating motor Support
FM Support
Rechargeable Lithium Battery 3.7V,7000mAh
Standby Standby current less than 10mA
Dimension 209mmx139mmx19mm
Weight 590g
Environmental Characteristics
Working Temperature -20 + 50
Storge Temperature -40 +60
Humidity 5% --95% relative humidity ;no condensation



R2000 Sensor Rfid Desktop Reader , Long Distance Rfid Reader Handheld With 1d / 2d Barcode
R2000 Sensor Rfid Desktop Reader , Long Distance Rfid Reader Handheld With 1d / 2d Barcode


FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF
