Touch Screen Multipara Monitor , Tabletop Type Patient Monitoring Equipment
Touch Screen Multipara Monitor , Tabletop Type Patient Monitoring Equipment
Specifications
Brand Name :
RONSEDA
Model Number :
RSD 5000B
Certification :
CE and ISO
Place of Origin :
China
MOQ :
1 Set
Price :
Usd 600 / Set
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1000 Set / Month
Delivery Time :
5-10 Working Days
Packaging Details :
Box
Parameter :
SPO2,ECG,NIBP,TEMP,PR,RESP
Screen :
5 Inch TFT Color Screen
Weight :
1.5 KG
Dimension :
15X20X32 CM
Standard :
SpO2 Sensor,ECG Cable,Temperature Probe,NIBP Cuff,NIBP Hose,Power Cable
Optional :
Printer
Description

5 Inch Touch Screen Tabletop Portable Multi-Parameter Patient Monitor

SPO2,ECG,NIBP,TEMP,PR,RESP

P/N:

RSD 5000B

INTRODUCTION:

1. Touch screen,5.0 inch color TFT-LCD, simple for operating, quickly&accurately measure the data;

2. Build-in rechargeable Li-battery, up to 15 hours running time, support AC and DC power;

3. Adjustable audible and visual alarms, and sensor off alarm;

4. Long time monitoring and sleeping monitoring;

5. Easy to carry, suitable for ambulance center.

STORAGE AND REVIEW:
Maximum Data Quantity: 3888 groups
Maximum Trend Time: Continuous 129.6 hours
PRINTER(OPTIONAL):
Type: Thermal micro-printer
Printer Paper: 58 mm thermal paper,Paper roll diameter≤Φ 33mm
Interface: Bluetooth wireless interface
Recording Types: Real-time printing and review data printing
Power Supply:
Rechargeable battery 1700mAh~2000mAh.7.2V.
Charge(discharge) ≧1000times.
Charge time: 2hours
Work Operation/relative humidity:0～55℃/10～80%RH
Storage Operation/relative humidity:–20～60℃/10～90%RH

FEATURES:

12.1 inch color TFT LCD display, 8 waveforms
Rechargeable high-quality Built-in Li-battery
Easy to learn and use with simplified menus and keys
Easy to connect with central monitoring system
Suitable for adult, pediatric and neonate
Supporting large capacity of storage
ST section and cardiac arrhythmia analysis anti-ESU and defibrillator
Display mode: Standard, Large Font, Trend Table, Full lead ECG, Oxy CRG

GENERAL SPECIFICATIONS:

Storage and review data up to 3888groups via Trend Graph and Trend List.

USB and Bluetooth data upload;

Big font screen interface is easy to observe;

Back light can be adjusted;

Free advanced software

ENVIRONMENT:
Temperature
Working:0°C～45°C
Transport and Storage: -25°C～85°C
Humidity
Working:30% ～85 %
Transport and Storage: 30% ～95 % (no condensation)
PARAMETERS:
ECG
Input:3- lead ECG cable, standard AAMI cable connector
Lead Selection:I,II,III
Gain Selection:×1,×2,×4,×8
Sweep Speed: 12.5, 25, and 50 mm/s
Frequency Response: None filter: 0.05～100Hz (-3dB), filter: 0.5～40Hz (-3dB)
Calibration Signal: 1mV square wave
Protection: Against electrosurgical interference and defibrillation
Heart Rate
Measuring Range: 20 bpm～300 bpm
Renew Time: 1 time per beat
Accuracy: ±1 bpm
Alarm Mode: Audible and visual alarm
SpO2
SpO2%
Measuring Range:0%～100%
Resolution:1 %
Accuracy:±2 %(90%～99%), ±3 %(70%～89%),unspecified (0%～69%)
Pulse Rate
Measuring and Alarm Range:20～300bpm
Resolution: 1bpm
Accuracy: ±1bpm
NIBP
Method: Oscillometric
Mode: Manual, Auto, STAT
Measuring Interval in AUTO Mode: 1, 2, 3, 5, 10, 15, 20, 30, 45, 60 (min)
Measuring Period in STAT Mode: 5 min
Cuff Pressure Range:0 mmHg～300mmHg
Pulse Rate Range:30 bpm～250bpm
Measurement Rage: Adult 30 mmHg～255mmHg, Pediatric 30 mmHg～160mmHg
Over-pressure Protection: Adult 300mmHg, Pediatric 220mmHg
Pressure Resolution : 1mmHg
The SYSTOLIC and DIASTOLIC values measured using this device shall be equal to those measured by trained medical personnel using cuff and stethoscope. The MEAN value measured using this device is equal to that measured using blood pressure measurement device.
Temperature
Input: Body surface thermal-sensitive resistor temperature sensor
Measuring Range: 0℃～50℃
Accuracy: ±0.1℃

WARRANTY:

One years after receiving item.

PICTURES:

Touch Screen Multipara Monitor , Tabletop Type Patient Monitoring Equipment
