Mindray PM7000 PM8000 PM9000 Patient Bedside Monitor Main Board Mother Board 9210-30-30150

►Brief Introduction

The Mindray PM8000 Patient Monitor Display Inverter Board High Voltage Board is a component of the patient monitor system manufactured by Mindray. It is responsible for converting the low voltage power supply from the monitor to high voltage power required to operate the display backlight. This high voltage is necessary to illuminate the screen and ensure clear visibility of patient readings and monitor parameters.

Mindray PM8000 patient monitor display inverter board high voltage board is to provide the necessary high voltage power to the monitor's display screen. This allows the display to produce bright and clear images for easy viewing by healthcare professionals. The high voltage board ensures that the display is properly powered and functioning effectively.It ensures that the display is properly illuminated and functions optimally.

► How To Use

Ensure that the PM8000 patient monitoring device is turned off and disconnected from the power source.

Open the PM8000 device by removing the screws on the back cover and carefully pulling off the cover.

Locate the Display Inverter Board inside the PM8000 device. It is usually connected to the main circuit board and is smaller in size.

Disconnect any cables or connectors attached to the Display Inverter Board. Make sure to handle them with care to avoid any damage.

Remove the old Display Inverter Board by unscrewing it from its mounting position. Be gentle while removing it to avoid any damage to other components.

Take the new Mindray PM8000 Display Inverter Board High Voltage Board and align it with the mounting position. Carefully screw it in place, ensuring that it is securely attached.

Reconnect the cables and connectors that were detached from the old Display Inverter Board. Make sure they are properly inserted, and each connector is connected to the correct port.

Double-check all connections and ensure that no loose cables are left behind.

Close the PM8000 device by placing the back cover back on and securing it with the screws.

Connect the PM8000 device to the power source and turn it on to test the new Display Inverter Board. If the device powers up and the display is functioning correctly, then the replacement was successful.
