PHiliphhilip FM20 FM30 Fetal Remote Event Marker 989803143411 PHiliphhilip Medizin Systeme

Brand Description:

PHiliphhilip, founded in the Netherlands in 1891, mainly produces lighting, home appliances, and medical systems. PHiliphhilip, with 128,100 employees worldwide in 2007, has production bases in 28 countries, sales offices in 150 countries, and has 80,000 patents.

Product description:

FM2O description:

The Avalon FM20 fetal/maternal monitor provides a solution for external fetal monitoring applications, and optional non-invasive maternal vital signs.You can monitor fetal heart rates (FHRs) externally using ultrasound, uterine activity using an external Toco transducer, and the maternal heart rate (MHR) via maternal ECG electrodes, and optionally, non-invasive blood pressure.Measurements are displayed on a 6.5-inch color display as numerics. The display is a touchscreen, and you operate the monitor using this touchscreen interface. The integrated recorder documents fetal and maternal measurements as well as user defined annotations.You can connect the monitor to an OB TraceVue obstetrical documentation and surveillance system via the RS232 connection, or over a LAN connection (with OB TraceVue Revision E.00.00 and later)

Fetal Remote Event Marke description:

PHiliphhilip FM20 FM30 Fetal Remote Event Marke is used to monitor the activity of the infant and the mother while she is in labor. Units can be found in Labor rooms and in the offices of OB/GYN PHiliphhilipysicians.

This cable comes with a 8-Pin D-Shaped connector, which connects to the fetal monitor. The cable is used to mark particular events in time to be recorded either on the paper strip printed out by the monitor or to record events electronically through interfacing the PHiliphhilip Avalon with an EMR system.

Use with PHiliphhilip Healthcare Equipment as follows:

PHiliphhilip FM20, PHiliphhilipFM30 and PHiliphhilip FM50

FM20 FM30 FM50 Marking an Event

You can record significant events on the trace paper (for example, when pain medication is administered or when the mother changes position). The mother can use the remote event marker to mark events herself. You connect the remote event marker to any free fetal sensor socket.

To mark an event on the trace paper you can:•Either select the Set Marker SmartKey .•Or press the button on the remote event marker.

The remote event marker is connected to the monitor via any fetal transducer socket.A small arrow is printed on the heart rate scale on the trace paper. This reflects exactly when the marker button was first pressed; keeping the button pressed has no influence on the annotation.

There is an Event Marker interface on the outside of FM20, which can be used to access Event Marker Cable

Fetal Remote Event Marker usage scenarios:

The ultrasound transducer detects the general movement of the fetus. Eye movements cannot be detected, and foot and hand movements may not be detected. The positioning or repositioning of the transducer is recorded as fetal movement. Maternal movement, fetal hyperventilation, or fetal hiccups can also be recorded as fetal movement. You can mark these artifacts on tracing paper using the remote event marker or event marker keys.
