GE B650 Patient monitor display high voltage board

Backlight Inverter Board LXMG1627-12-61

► Brief Introduction of GE B650 Patient monitor display high voltage board Backlight Inverter Board LXMG1627-12-61

The GE B650 Patient Monitor is a medical device used to monitor a patient's vital signs, such as heart rate, blood pressure, and oxygen levels. The monitor is equipped with a backlight inverter board, which is responsible for providing the necessary power to the monitor's backlight so that information can be displayed clearly and brightly.

The backlight inverter board is an important component of the patient monitor because it controls the brightness and contrast of the display, ensuring that medical staff can easily read and interpret the displayed data. Without a properly functioning backlight inverter board, the monitor may not display accurate or readable information, which may affect patient care.

When replacing or troubleshooting the backlight inverter board on the GE B650 Patient Monitor, always consult the user manual or contact a qualified service technician for guidance. Always ensure that the monitor is turned off and unplugged from the power supply before attempting any maintenance work on the device. Or if you have other questions, you can also feel free to contact us and we will give you professional guidance.

Overall, the backlight inverter board is a key component of the GE B650 Patient Monitor, providing the necessary power to the monitor's display so that the patient's vital signs can be clearly and accurately monitored.

► The function of GE B650 Patient monitor display high voltage board Backlight Inverter Board LXMG1627-12-61

This display model requires a backlight inverter board that connects to the DC/DC board with an inverter cable and to the LCD display with two dual-wire backlight cables.

The backlight inverter board takes care of the following functions:

-It contains transformers that convert the +12 V input voltage received from the DC/DC board to high frequency, high-voltage output required to ignite and operate the 2 CCFL lamps. -

-It receives the backlight enable (on/off) signal from the CPU Board.
