GE Carescape B650-01 Touch Screen Patient Monitor Used

►Quick Detail:

This product is GE Carescape B650-01 Touch Screen Patient Monitor, used good condition
The monitor equipment is managed by power supply CPU, Composed of display, user interface, and external interface; A touch screen for a 15 inch LCD display with an LED backlight unit;
The power management subsystem provides working voltage equipment for electronic devices and is responsible for battery management. It consists of an AC/DC power supply, a DC/DC power management board, and an optional lithium-ion battery. The CPU board is the main board of the monitor. It is responsible for user input and data processing, and displays the processed information on the screen. It controls the operation and communication between the monitor and other subsystems. The display controller is integrated into the CPU.

►The GE Carescape B650-01 Touch Screen display includes:

(1) Alarm light
(2) Power on/standby button
(3) Power indicator light
(4) Integrated keyboard
(5) Fine tuning knob control
(6) Environmental light detector lens
(7) Audio alarm pause/turn off area (blue)
(8) Alarm light area (blue, yellow, or red)
(9) Power voltage indicator light - When the monitor is connected to an AC power source, the green LED lights up.
(10) Battery usage indicator light - When the monitor is working on battery, the green LED lights up
Power.

This monitor is second-hand and may encounter touch screen calibration issues. Normally, it does not need to be recalibrated during normal use. If calibration is required, the following methods can be used:

1. Select Monitor Settings>Service Calibration.
In the "Enter Password" dialog box, type your username and password, and then press Enter.
user name: biomed
Password: Change<space>me
Note: Usernames and passwords are case sensitive.
3. In the maintenance/calibration menu, select Touch Screen. Touch calibration screen
Open it.
4. Touch the crosshairs in every corner of the screen (+).

►Key features:
