FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service
FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service
FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service
FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service
FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service
FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service
Specifications
Brand Name :
FASTPCBA
Model Number :
Multilayer PCBs Assembly
Certification :
IATF16949, ISO13485, ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
1-20
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
150000 Pieces per Month
Delivery Time :
5
Packaging Details :
PCB: Vacuum Packing/ PCBA: ESD Packing
Service :
One-stop Pcb assembly
Laminate materials :
FR4, High TG FR4, High Frequency, Alum, FPC
Number of layers :
1-48
Min space :
0.075mm
PCBA Testing :
X-ray,AOI Test,Functional test
Sub-assembly :
Plastic,metal,screen
Description

PCB Printing Service Turnkey Medical PCBA Prototype fr4 94vo Rohs PCB Board

Product Specification:

Article Description Capability
Sercive PCB and SMT assembly with one-stop service
Material Laminate materials FR4, high TG FR4, high frequency, alum, FPC
Board cutting Number of layers 1-48

Min.thickness for inner layers

(Cu thickness are excluded)

 0.003”(0.07mm)
Board thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twist 7/1000
Copper weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)

Solder mask

 Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
E-test Function Test 100% Functional test
PCBA Testing X-ray,AOI Test,Functional test
Pcb assembly one-stop service electronic manufacxturer service
Component sourcing Yes
Certificate IATF16949,ISO9001
Delivery time: PCB 3-12days
PCBA 8-20days
Tolerance of pcb ±5%
Max size of finish board 450*450mm
MOQ NO MOQ (1pcs)
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB outline Square,circle,irregular(with jigs)
package QFN,BGA,SSOP,PLCC,LGA
Sub-assembly Plastic,metal,screen

FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service

OUR ADVANTAGE


Quality System: Passed ISO9001 / ISO13485 / TATF16949:2016 quality system certification, processed products meet export European and American standards


Professional team: Professional component procurement team, centralized procurement, saving procurement costs, labor costs, quality costs for you.


No MOQ:As for MOQ, one piece PCB prototype is ok for us. FASTPCBA full support from proofing to batch


Global Support:Major customer groups: automotive, medical electronics, industrial, security, communication, power and so on.


NDA:We are willing to sign the NDA agreement in accordance with the local laws of customers and promise to keep customer data confidential


Delivery 24 hours:Professional prototype: PCB prototype is delivered within 24 hours.Mass production, the fastest delivery time is 2-5 days

FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service

FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service

FASTPCBA is a one-stop comprehensive PCB manufacturing and assembly manufacturer of high-precision large, medium and small batch printed circuit board, and electronic component procurement.

FASTPCBA relies on the MY500 solder paste printer imported from Sweden, which can realize fast turnover line, no stencil solder paste printing, and fast delivery within 4 hours. MYDATA Sweden’s fully automatic SMT production line, with a daily production capacibility of 3 million points plus top-level quality control and testing equipment, controlled strictly by 9 “testing procedures”, high standards of anti-static, 5,000 square meters of dust-free production workshops, strictly implemented IATF 16949 / ISO13485 quality system standard, and obtained ISO9001-2016 quality management system certification, and to be a socially responsible company for customers, employees.

FASTPCBA is famous for high precisions pcb fabrication and assembly service around the world. Especially aerospace electronic automotive, medical, industrial, smart home, communication, military pcba customers prefer to cooperate with us.

FR4 94v0 RoHS Multilayer Rigid Flexible Prototype PCB Printing Service
