High Volum PCB Assembly multilayer pcb manufacturing process

Shinelink PCBA is your source for fast affordable mid to high volume production runs of printed circuit board assemblies.we have over 15 years’ experience in PCB Assembly. We specialise in manufacturing mid to high-volume PCB assembly for the automotive, electronics, aviation and medical device industries.

Files Requested For PCB Assembly Quotation


---In order to provide you with the most efficient and accurate quote on manufacturing the requested unit, we ask that you provide us with the following information.
1. Gerber file,PCB file,Eagle file or CAD file are all acceptable
2. A detailed bill of materials (BOM)
3. Clear pictures of PCB or PCBA sample for us
4. Quantity and delivery required
5. Test method for PCBA to guarantee 100% good quality products.
6. Schematics file for PCB design if need to do function test.
7. A sample if available for better sourcing
8. CAD files for enclosure manufacturing if required
9. A complete wiring and assembly drawing showing any special assembly instructions if required

Shinelink PCBA’s PCB Assembly Services

Shinelink PCBA is a fully modern electronic manufacturing services (EMS) company. We offer the full range of services you need to assemble your printed circuit board, including:

  • Surface Mount Pick & Place Technology (SMT)

  • Through Hole Selective Soldering

  • Screen Solder Paste Printing or Jet Solder Paste Printing

  • Hand Solder & Assembly Services

  • Full Functional Test Capabilities

  • RoHS Bill of Material Conversions

  • Conformal Coating and Potting

Shinelink kinds PCBA Products

Multilayer Prototype Circuit Board Assembly High Volum PCB Manufacturing Process

Our PCB Manufacturing Capabilities

Types of PCB Assembly

Surface Mount, Through Hole, Mixed Assemblies

Lead or Lead Free

Single or Double Sided

No Clean Fluxes, Lead or Lead-free

Programs

Prototyping and Fast Turn

Full Turnkey Assembly

Consignment / Kanban / Order-Fulfillment Programs

Labor Only / Customer Owned Components

Components

Passives parts, smallest size 01005

Fine pitch to 8 Mils

BGA, uBGA, QFN, POP and Leadless chips

Connectors and terminals

Accepted Component Formats

Reels, Digi-Reels

Cut tape (allow leader or overage)

Tube and tray

Loose parts and bulk. Now offering reeling services.

PCB Board shape

Rectangular

Round

Slots and Cut outs

Complex and Irregular

PCB Board dimensions

Smallest size: 1.2″ x 1.2″ (30 x 30 mm)

Largest size: 15.1″ x 20″ (384 x 508 mm)

Thickness Range: 0.02″ – 0.1875″ (0.5 – 4.76 mm)

Clearances & Weights

Board edge: 0.02″ – 0.14″ (0.5 – 3.5 mm)

Top side: 0.50″ – 0.60″ (12.5 – 15 mm)

Bottom side: 1.25″ (32 mm)

Max board weight: 9lbs (4kg)

PCB Board type

Rigid FR-4, Rigid-Flex Boards

Flexible, Flat-Flex (FFC)

PCB Assembly process

Leaded process

Lead-Free (RoHS)

Testing capabilities

X-ray Inspection

AOI (Automated Optical Inspection)

ICT (In-Circuit Test) / Functional testing / Bed of Nails

Design file format

Gerber RS-274X

BOM (Bill of Materials) (.xls, .csv, . xlsx)

Centroid (Pick-N-Place/XY file)

Oven profile

Standard Reflow

Custom Reflow

Turnaround time

1-5 days for only PCB assembly

10-16 days for turnkey PCB assembly

Multilayer Prototype Circuit Board Assembly High Volum PCB Manufacturing Process

Product tags

pcb electronics manufacturing

,

electronics manufacturing pcb

,

fabrication of main pcb
