Quick Turn High Frequency PCBs Boards Proto PCB Circuit Board
Keyword :
Digital PCB
Service :
One-stop Service
Layer Count :
1-48
Testing Service :
Function Test, 100% Test
MOQ :
No MOQ
PCBA Test :
X-ray,AOI Test,Functional test
Solder mask color :
Yellow,green,blue,white,black
Description

China PCBA Manufacturer Custom Made Automotive / Medical / Industrial Control PCB PCBA Circuit Board

As complexity of electronic components increases, the one thing that becomes imperative is signal rates and high frequency of transmission. Little surprise then that the demand for high frequency PCBs is on the rise. They find use in a variety of high-speed design applications that require a frequency range of 500MHz to 2GHz.

.

Article Description Capability
Material Laminate materials FR4, High TG FR4, High Frequency, Alum, FPC...
Board Cutting Number of layers 1-48
Min.thickness for inner layers
(Cu thickness are excluded)		 0.003”(0.07mm)
Board Thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twist no more than 7/1000
Copper Weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)
Solder Mask Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
Max Size of Finish Board 700*460mm
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB Outline Square,circle,irregular(with jigs)
Package QFN,BGA,SSOP,PLCC,LGA

FASTPCBA is the high tech pcb factory in china over 20 years, our pcba service scope: middle and small batch quick pcb prototype, turnkey pcb assembly, high quality custom pcba manufacturing, original package components procurements etc.

Quick Turn High Frequency PCBs Boards Proto PCB Circuit Board

Delivery Time for PCB

Layer Prototype

Mass Productions

(above 30 m2 )
Quick Turn Unual Time
2 24 hours 3-4 days 8-10 days
4 48 hours 5-6 days 10-12 days
6 72 hours 6-8 days 12-14 days
8 96 hours 8-10 days 14-16 days
10 120 hours 12-14 days 16-18 days
... ... ... ...

Delivery Time for PCBA

Order Conditions Standard Delivery Date The fastest Delivery Date
Prototype (<20 pcs) 2 days 8 hours
Small Volum (20-100 pcs) 3 days 12 hours
Medium Volum(100-1000 pcs) 6 days 24 hours
Mass productions (>1000 pcs) Depends on BOM Depends on BOM

With complete dust free & esd protection smt workshop, FASTPCBA has win trust and support from domestic and abroad customers of industrial control, medical,power communication, automotive etc. All pcba products here abide by IATF16949 & ISO14000 & ISO13485 & ISO9001 certificates, reliable and stable pcb manufacturing and assembly service are assured.

Quick Turn High Frequency PCBs Boards Proto PCB Circuit Board

FASTPCBA believes quality derives from profession, reputation wins the future. From grass-roots employees to senior management all concentrate on precise and high quality pcba solutions to provide better service for customers.
