Shenzhen PCBA Manufacturer Provide SMT Electronic Components PCB Assembly Service

Technical Requirement for pcb assembly:

1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line.
7) High density interconnected board placement technology capacity.

Production Requirement for pcb assembly:

1. Gerber Files (Eagle and PCB File are available).
2. BOM list.
3. Clear pictures of PCBA or PCBA samples to us.
4. Pick N Place file.
5. Test procedure for PCBA.

Small Quantity SMD Through Hole PCB Assembly Circuit Card Assembly Manufacturing

1.Detailed Specification of PCB Board Manufacturing

1 Layer 1-48 layer
2 Material FR-4,CEM-1,CEM-3,Hight TG,FR4 Halogen Free,FR-1,FR-2,Aluminum
3 Board thickness 0.4mm-4mm
4 Max.finished board side 700mm*460mm
5 Min.drilled hole size 0.25mm
6 Min.line width 0.10mm(4mil)
7 Min.line spaceing 0.10mm(4mil)
8 Surface finish/treatment HASL/HASL lead free,Chemical tin,Chemical Gold,Immersion gold Inmersion Silver/Gold,Osp,Gold Plating
9 Copper thickness 1/2OZ 1OZ 2OZ 3OZ
10 Solder mask color green/black/white/red/blue/yellow
11 Inner packing Vacuum packing,Plastic bag
12 Outer packing Standard carton packing
13 Hole tolerance PTH:±0.076,NTPH:±0.05
14 Certificate IATF16949, ISO13485, ISO9001
15 Profiling Punching Routing,V-CUT,Beveling
16 Assembly Service Providing OEM service to all sorts of printed circuit board assembly

2.Detailed Terms for PCB Assembly

Technical Requirement Professional Surface-mounting and Through-hole soldering Technology
Various sizes like 1206,0805,0603 components SMT technology
ICT(In Circuit Test),FCT(Functional Circuit Test) technology
PCB Assembly With UL,CE,FCC,Rohs Approval
Nitrogen gas reflow soldering technology for SMT
High Standard SMT&Solder Assembly Line
High density interconnected board placement technology capacity
Quote&Production Requirement Gerber File or PCB File for Bare PCB Board Fabrication
Bom(Bill of Material) for Assembly,PNP(Pick and Place file) and Components Position also needed in assembly
To reduce the quote time, please provide us the full part number for each components,Quantity per board also the quantity for orders.
Testing Guide&Function Testing method to ensure the quality to reach nearly 0% scrap rate
OEM/SMT/EMS Services PCBA, PCB assembly: SMT & PTH & BGA
PCBA and enclosure design
Components sourcing and purchasing
Quick prototyping
Plastic injection molding
Metal sheet stamping
Final assembly
Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
Custom clearance for material importing and product exporting
Other PCB Assembly Equipments SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4
Reflow Oven: FolunGwin FL-RX860
Wave Soldering Machine: FolunGwin ADS300
Automated Optical Inspection (AOI): Aleader ALD-H-350B,X-RAY Testing Service
Fully Automatic SMT Stencil Printer: FolunGwin Win-5

Small Quantity SMD Through Hole PCB Assembly Circuit Card Assembly Manufacturing

FASTPCBA is the independent export pcba assembly factory over 20 years, who are recognized as the top 10 pcba manufactuerer global, serving for customers of safety protection pcba, automotive circuit board, medical pcba, industrial pcba, communication pcba, smart home pcba, aviation pcba and military pcba etc.
