Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing
Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing
Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing
Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing
Specifications
Brand Name :
FASTPCBA
Model Number :
Prototype PCB Assembly
Certification :
ISO13485, IATF16949, ISO9001,IOS14001
Place of Origin :
China
MOQ :
1 PCS
Price :
Negotiable (Depends on your gerber and bom)
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30000pcs/month
Delivery Time :
1-30 work days
Packaging Details :
PCB: Vacuum Packing / PCBA: ESD Packing
Name :
Quick Turn PCBA Prototype Pcb Fabrication Pcba Assembly Manufacturing BGA Assembly
Keyword :
Pcba Printed Circuit Board Assembly
Service :
Prototype Pcba Service
Max board size :
700x460 mm
Minimum IC Pitch :
0.2mm
Number of layers :
1-48
Minimum PCB thickness :
0.25mm
Maximum BGA size: :
74x74mm
Sub-assembly :
Plastic,metal,screen
Surface Finish :
HASL,ENIG,immersion silver,immersion tin,OSP…
Process Characteristics :
HDI Blind Buried Hole Process, High BGA Density, Small Hole-To-Line Spacing
Solder mask :
Green, Blue, Black, White, Yellow, Red, Matt Green, Matt Black, Matt Blue
Description

Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing

FASTPCBA is a professional PCB / PCBA Manufacturer in China, Shenzhen. With 20 years of development, FASPCBA turns into a first class manufacturer of PCB / PCBA. From multi-layered to flexible printed circuit boards, FASTPCBA is your one-stop shop. We provide our customers with PCB Manufacturing, PCB Assembly and Parts Sourcing service to save your time & cost.

PCB Manufacturing


As a 20 years PCB manufacturer in China, FASTPCBA is providing the latest printed circuit board technologies and highest quality standards for electronics industry. You can trust us to meet your demands, from small volume to mass production whatever the simplest PCB boards or the most complex.

1. Accept Stardard: IPC III, Military, Automotive, Medcial, We offer you expanded PCB capabilities: Rigid PCB, Flexible, Rigid-flex, HDI board, High TG PCB.

2. Manufacture PCB board up to 48 layer, Raw material: Fr4, Rogers, Arlon, Teflon, Taconic, Nelco, Isola, Ceramic, Metal core.

3. Support PCB surface process: HASL-LF, ENIG, Plating gold, Immersion tin, Immersion silver, ENIPIG, OSP.

PCB Manufacturing Capability:

Article Description Capability
Laminate Materials FR4, high TG FR4, high frequency, alum, FPC
Board Cutting Number of layers 1-48
Min.thickness for inner layers
(Cu thickness are excluded)		 0.003”(0.07mm)
Board Thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twist no more than 7/1000
Copper Weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)
Solder Mask Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
Component Sourcing Yes
Tolerance of PCB ±5%
Max Size of Finish Board 700*460mm
MOQ NO MOQ (1pcs)
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB Outline Square,circle,irregular(with jigs)
Package QFN,BGA,SSOP,PLCC,LGA
Sub-assembly Plastic,metal,screen
Min Line/Space 0.075/0.075mm

Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing

PCB Assembly


FASTPCBA is China PCB assembly manufacturer ,who offers complete PCB assembly services in Shenzhen , FASTPCBA’s capable of providing turn-key and partial turn-key printed circuit board assembly services.

For full turn-key, we take care of the entire process, including manufacturing of Printed Circuit Boards, procurement of components (100% original) , PCBA Testing , continuous monitoring of quality and final assembly.

PCB Assembly Capability

Minimum IC Pitch

0.2mm

Maximum PCB size

700x460 mm

Minimum PCB thickness

0.25mm

Minimum chip size:

0201 (0.2x0.1)/0603 (0.6 x 0.3mm)

Maximum BGA size:

74x74mm

BGA ball pitch:

1.00mm (minimum), 3.00mm (maximum)

BGA ball diameter:

0.40mm (minimum), 1.00mm (maximum)

QFP lead pitch:

0.38mm (minimum), 2.54mm (maximum)

Volume:

One piece to low volume production quantities
Low cost first article builds
Schedule deliveries

Assembly type:

Surface mount(SMT) assembly
DIP assembly
Mixed(surface mount and through hole) technology
Single or double sided placement
Cable assembly

Components type:

Passive components:
As small as 0402 package
As small as 0201 with design review
Ball Grid Arrays(BGA):
As small as .5mm pitch

Parts procurements:

Turnkey(we supply the parts)
Consigned(you supply the parts)
You supply some parts, we do the rest

Solder type:

Leaded
Lead-free/ROHS compliant

Other capabilities:

Repair/rework services
Mechanical assembly
Box build
Mold and plastic injection.

Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing

FASTPCBA Electronics Co., Ltd., owns leading quality control inspection equipment and high-standard anti-static as well as dust-free workshop production environment in electron industry.

By virtue of 0.1mm laser drilling, 100% AOI detection between layers, tightly controlled multi-layer compression equipment, super-speed flying-probe tester, and the quality of PCB is guaranteed powerfully from hardware and details.

Quick Turn PCBA Prototype Pcb Fabrication BGA Assembly Manufacturing

With advanced 3D online AOI/ selective wave soldering/ X-RAY etc machine, FASTPCBA can satisfy customers of medical pcba, automotive pcba, industrial pcba, smart home pcba, communication pcba, aerospace pcba and military pcba etc.
