Shenzhen PCB Assembly Customized Electronic Circuit Board Assembly

Bare PCB Manufacturing

Offering: Rigid PCB; Flexible PCB; Rigid-flex PCB; HDI PCB; Gold-Plated PCB; High Frequency PCBs; Aluminum PCB; Copper Base Circuit Board; High TG PCB; Heavy Copper PCB......

Our Circuit Card manufacturing and Assembly Capabilities:

Article Description Capability
Laminate Materials FR4, high TG FR4, high frequency, alum, FPC
Board Cutting Number of layers 1-48
Min.thickness for inner layers
(Cu thickness are excluded)		 0.003”(0.07mm)
Board Thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twist no more than 7/1000
Copper Weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)
Solder Mask Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
Component Sourcing Yes
Tolerance of PCB ±5%
Max Size of Finish Board 700*460mm
MOQ NO MOQ (1pcs)
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB Outline Square,circle,irregular(with jigs)
Package QFN,BGA,SSOP,PLCC,LGA
Sub-assembly Plastic,metal,screen
Min Line/Space 0.075/0.075mm

PCB Assembly Services
FASTPCBA offers full Turn-Key and partial Turn-Key Circuit Board Assembly Services. We focus on both rigid PCB Assembly and flex PCB assembly. Our quality driven PCB assembly process ensures that your finished project is of the highest quality. In Full Turn-Key PCB, we handle everything including making circuit boards, ordering components, quality inspection and final assembly. In partial Turn-Key, you can order the PCBs and partial components, we will fix the remaining parts for you.

1-48 Layer ICT 3oz Copper PCB Assembly HASL High Frequency

Testing Procedures

Various testing method will be applied to the assembled boards before the final shipment:

* Visual inspection: general quality check.

* FAI: full quality check applied to the first PCB to pass through all stages of production.

* X-ray Inspection: checks for BGAs, QFN and bare circuit boards.

* AOI Testing: checks for solder paste, 0201 components, missing components and polarity.

* 3D AOI Testing: checks for missing and misplaced SMT components in three dimensions.

* 3D SPI Testing: measures the precise volume of solder paste for SMT assembly.

* ICT (In-Circuit Test).

* Functional test (Following your test procedures).

1-48 Layer ICT 3oz Copper PCB Assembly HASL High Frequency

ISO Certification

FASTPCBA's production facilities are ISO9001 certified to ensure we go beyond your expectations.

1-48 Layer ICT 3oz Copper PCB Assembly HASL High Frequency

FAQ:

1, What service do you have?
We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing and other value-added service.

2, What is needed for PCB & PCBA quotation?
For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).
For PCBA: PCB information, BOM,Testing documents.

3, How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.

4, What are the main products of your PCB/PCBA services?
Automotive, Medical, Industry Control, IOT, Smart Home, Military, Aerospace.

5, What is your minimum order quantity (MOQ)?
Our MOQ is 1 PCS, sample and mass production all can support.

6, Are you factory?
Our factory is located in 1st Building, No. 18-1, Yuquan East Road, Yulv Village, Gongming Street, Guangming New District shenzhen, china.
