Specifications
Brand Name :
Abis
Model Number :
HDI PCB008
Certification :
ISO14001, ISO9001, UL, cUL, TS16949
Place of Origin :
Made in China
MOQ :
1
Price :
0.01$-10$
Payment Terms :
T/T, Paypal, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
72,000sqm per month
Delivery Time :
1-15 working days
Packaging Details :
vacuum package
Raw Material :
KB FR4 TG170
Board Thickness :
1.6mm, ±10%
Layers :
6
Soldermask :
Blue
Silkscreen :
White
Surface Finishing :
ENIG 2u"
Copper Thinckness :
2OZ
E-Testing :
100% Short & Open Test
Mini line width :
0.15mm
Mini Holes :
0.15mm
Description

Fr4 Tg170 Enig 2 u'' HASL Material Multilayer PCB Supplier Green solder white silk

Kindly find our advantage below:
. Material FR4, Rogers, CEM-1, CEM-3, FR-1, Aluminum for your market, Up to 20 Layer and HDI Board
. More than 10 years in this line and serve the customer with Intel(Buried and blind vias below picture shows)
. Passed ISO, UL, SGS certificates

What is a HDI PCB?

IPC-2226 defines HDI as a printed circuit board with a higher wiring density per unit area than conventional printed circuit boards (PCB). They have finer lines and spaces ≤ 100 µm / 0.10mm, smaller vias (<150 µm) and capture pads <400 µm / 0.40mm, and higher connection pad density (>20 pads/cm2) than employed in conventional PCB technology.


Product We Produce:

1. Rigid, Flex, Rigid-Flexible PCB.
2. Buried/Blind Vias, Via in Pad, Counter Sink Hole, Screw Hole(Counterbore), Press-fit, Half Hole.
3. HASL lead-free, Immersion Gold/ Silver/Tin, OSP, Gold plating/finger, Peelable mask,
4. Printed Circuit Boards adhere to IPC Class 2 & 3 international PCB standard.
5. Quantities range from prototype to medium & big batch production.

6. 100% E-test


Multilayer HDI PCB Production Range:

Number of layers 4 – 22 layers standard, 30 layers advanced
Technology highlights Multilayer boards with a higher connection pad density than standard boards, with finer lines/spaces, smaller via holes and capture pads allowing microvias to only penetrate select layers and also be placed in surface pads.
HDI builds 1+N+1, 2+N+2, 3+N+3,4+N+4, any layer in R&D
Materials FR4 standard, FR4 high performance, Halogen free FR4, Rogers
Copper weights (finished) 18μm – 70μm
Minimum track and gap 0.075mm / 0.075mm
PCB thickness 0.40mm – 3.20mm
Maxmimum dimensions 610mm x 450mm; dependant upon laser drilling machine
Surface finishes available OSP, ENIG, Immersion tin, Immersion silver, Electrolytic gold, Gold fingers
Minimum mechanical drill 0.15mm
Minimum laser drill 0.10mm standard, 0.075mm advanced


Testing:

E-testing

100%

QFP Pitch

16mil (0.40mm)

BGA Pitch

16mil (0.40mm)

Connector Pitch

16mil (0.40mm)

AOI

All Multilayer

Impedance Control

± 10%

Solderability Testing

As standard

Ionic Contamination

On Request

Why choose us:

Abis Circuits Co.,ltd is a professional PCB manufacturer in China, Shenzhen. With 15 years+ development, we could make the PCB from 1L to 20L, with monthly production capability 50,000 square meters. Abis Circuits is providing high quality bare PCB and PCB assembly service, including components sourcing, function test, conformal coating and complete assembly for clients all over the world, Our main market is Europe, north USA, Australia, South America, and Asia.

Millions of circuit boards are produced here every year, which provides superior service for automotive electronics, medical electronics, power communications, industrial automation, intelligent home and other industries around the world. We will continue to improve our quality and service; customer satisfaction and development of science and technology are our eternal motivation.

We have imported the advanced machinery from US, Japan, Germany to improve our production and technical ability. We have set a great example the PCB field of flying probe testing, buried and blind via and special controlled impedance. We have a highly developed R&D division which has helped our factory successfully produce mechanical micro via,high density impedance and HDI.


Our mission:


PCBs for demanding customers, on time with zero defects, produced sustainably at the lowest total cost. Manufacturing many different types of PCBs in smaller series (High-mix, Low-volume) involves constantly adjusting, adapting and problem solving.

Our responsibility:

We know that the PCB is a critical key component for our customers. And we know for sure that anything can happen during the complex production process involved – and it often does. In our world, taking full responsibility means a lot of things, including a responsible and sustainable approach in everything we do – socially, environmentally and ethically. When a problem occurs, we try as hard as we can to understand the problem and find a solution. Our mindset is that we own the problem and don’t leave until we have cleared it up.

Delivery Time:

Category Quickest Lead Time Normal
Double sides 24 hrs 120hrs
4 Layers 48 hrs 172hrs
6 Layers 72 hrs 192hrs
8 Layers 96 hrs 212hrs
10 Layers 120 hrs 268hrs
12 Layers 120 hrs 280hrs
14 Layers 144 hrs 292hrs
16-20 Layers Depends on the specific requirements
Above 20 Layers Depends on the specific requirements



FAQ :

Q1: How can I got quotation:
A: Please send gerber file with format: .PCB / .P-CAD / .DXP / .CAD / .Gerber

Q2: Do you have pcb in stock?
A: Most of our pcb board are customised, which according to gerber file.
ABIS have sample in stock could sent to you for a quality checking always.

Q3: What board manufacturer do you use for FR4?
A: Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan) and Shengyi (China).

Q4: Will my PCB files be checked?
A: Checked within 12 hours. Once Engieer question and working file checked, production will start.

Q5: What do you require in order to produce an assembly quotation?
A: Bill of materials (BOM) detailing:
a), manufacturers parts numbers ,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
d), Quantity

Q6: Does ABIS CIRCUITS bevel gold fingers?
A: Yes. A standard 45-degree bevel, also bevel at 15 or 30 degrees upon request. For multi-layer board, please ensure there is adequate back set forthe bevels.

Q7: My assembly company need the PCBs as panelized, can you do this for me?
A: Yes. We can panelize your circuits upon your request.
