FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards
FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards
FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards
FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards
Specifications
Brand Name :
ABIS
Model Number :
PCB-2Green
Certification :
ISO14001, ISO9001, UL, cUL, TS16949
Place of Origin :
Made in China
MOQ :
1
Price :
Customized
Payment Terms :
T/T, Western Union, paypal ect.
Supply Ability :
60,000sqm per month
Delivery Time :
1-15 working days
Packaging Details :
vacuum package
Base material :
FR4
Copper :
70um/2OZ
PCB Thickness :
2.0 mm
Surface finishing :
HASL LESD FREE
Solder mask :
Green
Silk :
White
Min. line width :
3mil
Min. hole size :
0.1mm
Application :
Electronics
Product name :
2 layers
Description

FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards

Item Spec
Layers 1~20
Board Thickness 0.1mm-8.0mm
Material FR-4, CEM-1/CEM-3, PI, High Tg, Rogers, PTEF, Alu/Cu Base, etc
Max Panel Size 600mm×1200mm
Min Hole Size 0.1mm
Min Line Width/Space 3mil(0.075mm)
Board Outline Tolerance 士0.10mm
Insulation Layer Thickness 0.075mm--5.00mm
Out Layer Copper Thickness 18um--350um
Drilling Hole (Mechanical) 17um--175um
Finish Hole (Mechanical) 0.10mm--6.30mm
Diameter Tolerance (Mechanical) 0.05mm
Registration (Mechanical) 0.075mm
Aspect Ratio 16:01
Solder Mask Type LPI
SMT Mini. Solder Mask Width 0.075mm
Mini. Solder Mask Clearance 0.05mm
Plug Hole Diameter 0.25mm--0.60mm
Impedance Control Tolerance 士10%
Surface finish ENIG, OSP, HASL, Chem. Tin/Sn, Flash Gold
Soldermask Green/Yellow/Black/White/Red/Blue
Silkscreen Red/Yellow/Black/White
Certificate UL, ISO 9001, ISO14001, IATF16949
Special Request Blind hole, Gold finger, BGA, Carbon ink, peelable mask, VIP process, Edge plating, Half holes
Material Suppliers Shengyi, ITEQ, Taiyo, etc.
Common Package Vacuum+Carton

FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards

Category Q/T Lead time Standard Lead Time Mass Production
2 Layers 24hrs 3-4 working days 8-15 working days
4 Layers 48hrs 3-5 working days 10-15 working days
6 Layers 72hrs 3-6 working days 10-15 working days
8 Layers 96hrs 3-7 working days 14-18 working days
10 Layers 120hrs 3-8 working days 14-18 working days
12 Layers 120hrs 3-9 working days 20-26 working days
14 Layers 144hrs 3-10 working days 20-26 working days
16-20 Layers Depends on the specific requirements
20+ Layers Depends on the specific requirements

FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards

Rigid pcb, Flex pcb, Flex-Rigid pcb

FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards

FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards

FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards

FR4 70um 2 Layer PCB Motherboard ISO14001 Green Printed Circuit Boards

Q1: How can I get a quotation:
. Please send gerber file with format: .PCB / .P-CAD / .DXP / .Gerber

Q2: Can you manufacture my PCBs from a picture file?
. Could you please provide a sample?

Q3: Do you have PCB in stock?
. Most of our PCB board are customized, which according to Gerber file.
. ABIS has samples in stock that could be sent to you for quality checking always.


Q4: What board manufacturer do you use for FR4?
. Main Suppliers(FR4): Kingboard (Hong Kong), NanYa (Taiwan), and Shengyi (China).

Q5: Will my PCB files be checked?
. Checked within 12 hours. Once Engineer's question and working file be approved, production will start.

Q6: What do you require in order to produce an assembly quotation?
. Bill of materials (BOM) detailing:
a), manufacturers parts numbers,
b), components suppliers' parts number (e.g. Digi-key, Mouser, RS )
c), PCBA sample photos if possible.
