8-layer FPC + SMT + TEST + DIP, SMT FPC Service, rigid flex FPC manufacturers, flexible printed FPC, multilayer FPC, flexible FPC

Product Description

Specifications
Our professional engineering team can put your project into production in a short time. Sample pictures and
BOM are needed to make customized products.Also we can supply for the copy of the FPC and FPCA, so you
just sent me the enquiry is ok, we can do what you need to do!
We can supply CAD and Pro-E designed precision moulds. Moulds can be designed and manufactured
according to customers' requests or samples. Plastic injection processing available.
Purchasing the electronic components for you to the production of the FPCA
We have advanced equipment for through-hole and SMT DIP COB cable Assembly

Product Details

1. 4-12-layer FPC production + SMT+TEST+DIP,SMT PCB Service,wooden box,rigid flex pcb manufacturers,high speed pcb layout
2. FPCBA processing method,Six-layer FPCHDI, laser hole 0.10mm, mobile phone motherboard,
3. FPC production + it contains SMT, DIP, TEST,

4. Printed circuit board (pcb) and PCBA products
   Communication terminal, communication station, electronic communication, optical fiber, optical module, communication equipment, communication instrument, computer, household appliance, testing equipment, testing instrument, instrument, SD card, SG card, mobile phone, computer, various antennas, cars, music Equipment, playback equipment, banking equipment, medical instruments, medical equipment, medical equipment, aerospace, aviation, military, LED, OLED, OLCD power control power supply, industrial power supply, communication power supply, automotive power supply, office equipment, digital products,computers,etc.Applications;
   Flexible circuit board (FPC) and FPCA product areas
   CD, hard disk, printer, fax machine, scanner, sensor, mobile phone, connector, module, walkie-talkie antenna card, high-end camera, digital camera, laser head, CD, medical, instrumentation, drive, automotive instrumentation, medical instrument, Medical equipment, banking equipment, industrial instruments, LED light bars, military, aviation, aerospace, defense and other high-tech products, of which more than 70% of the products are exported to Europe, America, Europe, Central Europe, Western Europe, Southeast Asia, Asia-Pacific and other countries and area.

PCB capability and services:

1. Single-sided, double-sided & multi-layer FPC (up to 30 layers)
2. Flexible PCB (up to 10 layers)
3. Rigid-flex PCB (up to 8 layers)
4. PI High TG, Polyimide, Aluminum-based material.
5. HAL, HAL lead free, Immersion Gold/ Silver/Tin, Hard Gold, OSP surface treatment.
6. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB standard.
7. Quantities range from prototype to volume production.
8. 100% E-Test

PCB, FPC process production capability

Detailed Specification of PCB Manufacturing

PCB Assembly services:

Automatic Pick & Place
Component Placement as Small as 0201
Fine Pitch QEP - BGA
Automatic Optical Inspection
Through-hole Assembly
Wave Soldering
Hand Assembly and Soldering

Material Sourcing
IC pre-programming / Burning on-line

Function testing as requested

Aging test for LED and Power boards

Complete unit assembly (which including plastics, metal box, Coil, cable assembly etc)
Packing design

Conformal coating
Both dip-coating and vertical spray coating is available. Protecting non-conductive dielectric layer that is

applied onto the printed circuit board assembly to protect the electronic assembly from damage due to

contamination, salt spray, moisture, fungus, dust and corrosion caused by harsh or extreme environments.

When coated, it is clearly visible as a clear and shiny material.
Complete box build
Complete 'Box Build' solutions including materials management of all components, electromechanical parts,

plastics, casings and print & packaging material

Testing Methods

AOI Testing
· Checks for solder paste
· Checks for components down to 0201"
· Checks for missing components, offset, incorrect parts, polarity
X-Ray Inspection
X-Ray provides high-resolution inspection of:
· BGAs
· Bare boards

In-Circuit Testing
In-Circuit Testing is commonly used in conjunction with AOI minimizing functional defects caused by

component problems.
· Power-up Test
· Advanced Function Test
· Flash Device Programming
· Functional testing

Detailed Specification of Pcb Assembly

FAQ:

Q: What files do you use in FPC fabrication?

A: Gerber or Eagle, BOM listing, X, Y sitting report, PNP and Components Position

Q: Is it possible you could offer sample?

A: Yes, we can custom you sample to test before mass production

Q: When will I get the quotation after sent Gerber, BOM and test procedure?

A: Within 6-48hours for FPC quotation and around 24-48 hours for FPCA quotation.

Q: According to the difficulty of high-layer boards, How can I know the process of my FPC production?

A: 7-35days for FPC production and components purchasing, and 14-20days for FPC assembly and Testing

Q: How can I make sure the quality of my FPC?

A: We ensure that each piece of FPC, FPCA products work well before shipping. We'll test all of them according to your test procedure.
