High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm
High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm
High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm
High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm
Specifications
Brand Name :
LEFANG
Model Number :
OT6001L370
Certification :
ISO9001, ISO14001, ISO/TS16949, SGS, UL, RoHs,OHSAS18000
Place of Origin :
Shenzhen,China
MOQ :
1 Piece
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
290, 000sqm Per Month
Packaging Details :
Inner: Vacuum Packing; Dry Packing out Packing
Delivery Time :
2-10 work days
Base Material/ Dielectric :
copper base
Layer Count :
1 layer single sided
Surface treatment :
OSP
Board thickness :
2.0 mm
Copper thickness :
2.0 mm
Solder Mask :
white
Board Size :
50 * 50 mm
Min. Aperture :
0.1 mm
Line Width/Spacing :
0.1 / 0.1 mm
Description

High Power LED Street Light PCB FR4 / Aluminum PCB Circuit Board with RoHS UL Certificate

For the LED PCB Circuit Boards, it is usually made with Metal Core as the board material. That's because LED PCB Circuit Boards always generate high volume of heat, and metal core based materials will help to transfer and dissipate the heat than the traditional rigid PCB Circuit Board.

How to get quick quotation?

High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm

Step 1 Please send us Gerber file with these format: .CAD / .Gerber / .PCB / .DXP / .P-CAD, etc
Step 2 Also please provide us the below details for quick quotation:

Board material: Fr - 4 / CEM - 1 / CEM - 3 / 22F / Fr - 1 / others
Material brand: SY / KB / Rogers (optional)
Material Specification:High Tg / copper based / aluminum based or others (optional)
Board thickness: 0.1 - 6.0 mm
Copper thickness: 0.05 Oz - 8 Oz ( 17 um - 288 um )
Surface Treatment: OSP / ENIG / HASL / Lead Free HASL / Immersion Tin / Immersion Sin
Color of solder mask and silk print: Green / red / blue / black / white / yellow ,etc
Board size and quantity

If you don't have Gerber file, please provide us the imfomation as step 2 or post your PCB Board to us for clone.

SAMPLE:

Board Basic Info - SAMPLE

Board material

Fr - 4

Material brand

KB

Material Specification

Tg 170

Board thickness

1.6 mm

Copper thickness

1 Oz

Surface Treatment

ENIG

Solder mask / sSilk print

Green / White

Board size

100 mm * 100 mm

Quantity

10k

Technical Data

High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm
Item Details
Max layer count 20 L
Max board thickness 6.0 mm
Max aspect ratio 10 : 1
Max copper thickness 6 OZ
Max dimension 600 * 700mm
Min thickness of 4 layers PCB 0.4 mm
Min hole / pad 0.15 / 0.35mm
Hole location accuracy + / - 0.05mm
PTH hole tolerance + / - 0.05mm
Min line width and line space 0.065 / 0.065mm
Surface treatment

HASL / HASL lead free, OSP

Immersion gold/silver/tin, gold plating (hard gold and soft gold),

silver plating, tin plating, platinum plating, carbon ink,

ENEPIG

(electroless nickel - electroless palladium - immersion gold)

Lead Time
High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm
Layer count Sample lead time/workday Batch lead time/workday
1-2L 2 6
4L 5 8
6L 5 9
8L 6 10
10L 8 10
12L 8 12
14L 10 15
16L 10 18
18-40L (Up to difficulty) at least 18 at least 24
P.S. For HDI, Blind/Buried Hole PCB: Regular Lead Time + 3 workdays

How to guarantee our high quality products?

High Power Led Street Light PCB , FR4 / Aluminum PCB Board For Led 50 * 50 Mm

-- We employ 70 professional engineers to ensure our high quality products.

Department Headcount
Electronic Eng. 13
R&D Eng. 15
PE Eng. 10
CAM Eng. 26
MI Eng. 6


Now send us your inquiry, and you will be replied within 8 hours!

Little knowledge - Single Sided PCB

Single sided PCB contains only one layer of conductive material, where components are focused on one side, and the other side of the wire is concentrated.

Single sided PCB are the best choice for low density designs. They are easily designed and quickly manufactured to serve as the most cost effective platform in the industry.

For surface finishes, single sided boards are available for Organic surface protectant (OSP), Immersion Silver, Tin, and Gold plating along with both leaded or lead-free Hot Air Solder Level (HASL), with operating temperatures range from 130℃ to 230℃.
