1-20 Layers Immersion Gold High Frequency Communication Circuit Board PCB
For the high frequency PCB Board, it is usually applied for communicaton area, which offers a frequency ranging from 500MHz - 2GHz. The layer count of this high frequency PCB is 4 and inner and outer copper thickness are 1 OZ / 35 µm. Also, the surface treatment of this high frequency PCB Board is Immersion Gold. Its minimum aperture is 0.2 mm, and the line width and space are 0.101 and 0.127 mm.
-- Lefang provides One-Stop solution to save your cost and time.
Quick Quotation - Competitive factory price is always offered |
Free Sample - Sample for free before mass production |
Quality Control - Sales Team monitors the production quality and lead time |
On Time Delivery - Customize the logistics plan according to customer’s requirement |
After-sale Service - Reply to the claim within 24 hours to make sure our customer’s manufacturing |
How to get quick quotation?
Step 1 Please send us Gerber file with these format: .CAD / .Gerber / .PCB / .DXP / .P-CAD, etc | ||||||||||||||||||||
Step 2 Also please provide us the below details for quick quotation: | ||||||||||||||||||||
Board material: Fr - 4 / CEM - 1 / CEM - 3 / 22F / Fr - 1 / others |
||||||||||||||||||||
Material brand: SY / KB / Rogers (optional) | ||||||||||||||||||||
Material Specification:High Tg / copper based / aluminum based or others (optional) | ||||||||||||||||||||
Board thickness: 0.1 - 6.0 mm | ||||||||||||||||||||
Copper thickness: 0.05 Oz - 8 Oz ( 17 um - 288 um ) | ||||||||||||||||||||
Surface Treatment: OSP / ENIG / HASL / Lead Free HASL / Immersion Tin / Immersion Sin | ||||||||||||||||||||
Color of solder mask and silk print: Green / red / blue / black / white / yellow ,etc | ||||||||||||||||||||
Board size and quantity | ||||||||||||||||||||
If you don't have Gerber file, please provide us the imfomation as step 2 or post your PCB Board to us for clone.
|
||||||||||||||||||||
SAMPLE:
|
||||||||||||||||||||
|
Lead Time
Layer count | Sample lead time/workday | Batch lead time/workday |
1-2L | 2 | 6 |
4L | 5 | 8 |
6L | 5 | 9 |
8L | 6 | 10 |
10L | 8 | 10 |
12L | 8 | 12 |
14L | 10 | 15 |
16L | 10 | 18 |
18-40L (Up to difficulty) | at least 18 | at least 24 |
P.S. For HDI, Blind/Buried Hole PCB: Regular Lead Time + 3 workdays |
Why you can trust our products?
-- What LEFANG's vision is to Make Our Customer's Products Better, so we try our best to fulfill the quality control
system andenvironmental management system. Our approved certification are as below:
ISO9001:2008 | ISO14001:2004 |
ISO/TS16949:2009 | OHSAS18000 |
UL | RoHS |
QC080000 | CQC |
Now send us your inquiry, and you will be replied within 8 hours!
