High Precision PCB Cutter Machine , 4000mm CNC V Groove Machine
High Precision PCB Cutter Machine , 4000mm CNC V Groove Machine
High Precision PCB Cutter Machine , 4000mm CNC V Groove Machine
High Precision PCB Cutter Machine , 4000mm CNC V Groove Machine
Specifications
Brand Name :
YUSH
Model Number :
YSVC-450C
Certification :
CE
Place of Origin :
Jiangsu China
MOQ :
1 sets
Price :
50000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 set/ week
Delivery Time :
3-5 days
Packaging Details :
Plyswooden Case
Description

High Precision PCB Cutter Machine , 4000mm CNC V Groove Machine

CNC V-CUT machine Features :

1. Environment-friendly self-lubricating design, low-friction controller.

2. Equal load in four directions

3. High-precision, maintenance free

4. High-speed and low noise,

5. Slide block is interchangeable

6. International standard specifications,

7. Full oil seal

8. High-rigid in four lines of steel balls

9. Smooth function and novel circulation

CNC V-CUT machine Parameters :

Max. width of steel sheet to be notched: 1220mm
Max. length of steel sheet to be notched 4000mm
Maximum thickness of steel sheet to be notched: 3.0mm
Min. thickness of steel sheet to be notched 0.8mm
Max. distance of the beam movement (backward and forward ) 1220mm
Resolution of beam movement (backward and forward) 0.001mm
Max. speed of beam movement: 800-2000mm/min
Max. distance of tool carrier movement (upward and downward) 100mm
Resolution of distance tool carrier movement (upward and downward) 0.001mm
Max. distance of sliding frame movement 4300mm
Max. speed of sliding rack 30m/min
Work-piece error within 4000mm ±0.05mm
Min. distance of V-trough edge 10mm
Positioning precision: ±0.05mm
Max. traveling length of tool carrier: 100mm
Control board height 660mm
Dimension: 6300*2300*1670(mm)
Gross weight 9000kg

High Precision PCB Cutter Machine , 4000mm CNC V Groove Machine
